NSN 5342-00-076-4084 NTA124015, NTA12401-5 , STSAE00705

Product Details | GROOVED CLAMP COUPLING

5342-00-076-4084 A metal loop having either a V or U cross section or channelled segment(s). It may be attached to a flat band. It is designed to create a fluid tight joint and/or connect pipe, tubing, tank cover(s), duct(s) and the like, by mating with flanged or beaded ferrule(s), flared, or beaded ends. It may or may not have a sealing inner liner. A latch or latches of the quick coupling type, nut or bolt type, or threaded trunnion type is (are) used to lock and adjust the band. Excludes COUPLING, CLAMP, PIPE and RING, LOCKING, METAL DRUM COVER.

Part Alternates: NTA124015, NTA12401-5 , STSAE00705, STSAE007-05 , BACC30M5 , BACC30M-5 , HL705, HL-70-5 , HL70-5 , HL795, HL79-5 , HS55815, HS5581-5 , GC501AW1595A, GN512H08, TE122000305, TE122-0003-05 , R2232P55 , 014761 , 014761-501 , 03A0705, 03A070-5 , 202-17002-5 , 23261595DS, 2326-1595DS, 59070031, 5907003-1 , 660145, 66014-5 , 5342-00-076-4084, 00-076-4084, 5342000764084, 000764084, 014761501, 202170025

Hardware and Abrasives | Hardware, Weapon System

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
53	01 JAN 1963	00-076-4084	20319 ( COUPLING, CLAMP, GROOVED )

Drawings & Photos | NSN 5342-00-076-4084

Part Number	Request Date	QTY	Origin
HL705	2024-11-327	5675	Israel
HL705	2024-07-190	758	Japan
HL705	2024-03-67	34	United States
HS55815	2023-09-244	6	United States
HL705	2023-03-74	60	Malaysia
HL705	2022-10-278	20	US
HL705	2022-09-244	516	Philippines
202170025	2022-07-199	17	US
HS55815	2022-05-151	20	Saudi Arabia
HL705	2021-08-238	2000	US
