Product Details | PADLOCK

5340-01-412-7004 A detachable portable fastening device, having a shackle or bow adapted to be opened for engagement through a staple or the link of a chain. The bow or shackle, when locked, is secured in the case by means of a spring-activated pin(s) entering a notch(es) in the shackle. The lock may be opened by inserting and turning a key or keys, by key insertion only, or by a predetermined setting on the dial of a combination lock. For two or more padlocks which are keyed alike and/or master keyed, see PADLOCK SET.

Part Alternates: ASL40KAS6BUSS6, ASTM F883, ASTMF883, DU34062, 5340-01-412-7004, 01-412-7004, 5340014127004, 014127004

Hardware and Abrasives | Hardware, Commercial

Supply Group (FSG) NSN Assign. NIIN
53 26 APR 1995 01-412-7004

Drawings & Photos | NSN 5340-01-412-7004


Demand History | NSN 5340-01-412-7004

Part Number Request Date QTY Origin
5340-01-412-7004 2024-07-207 6 US
5340-01-412-7004 2024-07-207 6 US
5340-01-412-7004 2024-04-102 4 US
ASTMF883 2022-09-244 2 US
ASTMF883 2022-04-116 1 US
5340-01-412-7004 2015-01-08 1 DIBBS
5340-01-412-7004 2013-10-280 1 DIBBS
5340-01-412-7004 2013-09-262 1 DIBBS
5340-01-412-7004 2013-09-261 3 US
5340-01-412-7004 2013-09-259 3 DIBBS

Cross Reference | NSN 5340-01-412-7004

Part Number Cage Code Manufacturer
ASL40KAS6BUSS6 38797 MASTER LOCK COMPANY LLC DBA MASTER LOCK
ASTM F883 81346 AMERICAN SOCIETY FOR TESTING AND MATERIALS
DU34062 80244 GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5340-01-412-7004

Technical Data | NSN 5340-01-412-7004

Characteristic Specifications
MATERIAL STEEL CORROSION RESISTING OVERALL
COLOR BRASS OR BRONZE
CONSTRUCTION LAMINATED OR SOLID
OPERATING MECHANISM TYPE BLADE TUMBLER OR DISK TUMBLER OR PIN TUMBLER
SHACKLE CLEARANCE 0.688 INCHES MINIMUM AND 1.500 INCHES MAXIMUM
SPECIAL FEATURES SET OF SIX PADLOCKS KEY OPERATED; KEYED ALIKE; SHACKLE DIA. 1/4IN., 9/32IN., 5/16IN. OR 3/8IN.; HORIZONTAL SIZE 3/4IN. CLEARANCE

Restrictions/Controls & Freight Information | NSN 5340-01-412-7004

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
No Freight Information

Management | NSN 5340-01-412-7004

Category Code Description
Materiel Category and Inventory ManagerE General Supplies (DLA/GSA Items)
Appropriation and Budget Activity2 Stock Fund Secondary Items
Management Inventory Segment2 NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code0 Medical Materiel
Weapons Systems/End Item or Homogeneous Group00DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements CodeX Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of SupplyGSAGeneral Services Administration
Washington, D.C. 20406
AgencyDADepartment of the Army
Service OrganizationAU.S. Army
ReparabilityZThis is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice CodesHDIRECT DELIVERY UNDER A CENTRAL CONTRACT # (VENDOR STOCKED) Issue, transfer or shipment is not subject to specialized controls other than those imposed by IMM/Service/Agency supply policy. 1. The item is centrally managed and procured. 2. Normal issue is by direct shipment from the vendor to the user at the order of the ICP or IMM. However, orders may be shipped from stock by ICP or IMM distribution facilities when the vendor's minimum order quantity is not met, or when stocks are being drawn down. 3. Requisitions and fund citations will be submitted in accordance with IMM/Service/Agency Requisitioning Procedures. 4. Generally delivery will be made within applicable Service/Agency guidelines addressing customer required timeframe.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Category Code Description
Cognizance Codes9QNavy-owned stocks of items accepted by the General Services Administration for support of Navy requirements
Naval Inventory Control Point, Mechanicsburg
Source of SupplyGSAGeneral Services Administration
Washington, D.C. 20406
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesHDIRECT DELIVERY UNDER A CENTRAL CONTRACT # (VENDOR STOCKED) Issue, transfer or shipment is not subject to specialized controls other than those imposed by IMM/Service/Agency supply policy. 1. The item is centrally managed and procured. 2. Normal issue is by direct shipment from the vendor to the user at the order of the ICP or IMM. However, orders may be shipped from stock by ICP or IMM distribution facilities when the vendor's minimum order quantity is not met, or when stocks are being drawn down. 3. Requisitions and fund citations will be submitted in accordance with IMM/Service/Agency Requisitioning Procedures. 4. Generally delivery will be made within applicable Service/Agency guidelines addressing customer required timeframe.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
