Product Details | BRIDGE CLAMP
5340-01-236-3519 A clamp designed to straddle a cover, door or like item, and used to secure such cover, door or like item to effect a tight joint or seal.
Part Alternates: 11752503, 1175250-3, 5340-01-236-3519, 01-236-3519, 5340012363519, 012363519
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 16 JUL 1986 | 01-236-3519 | 11206 ( CLAMP, BRIDGE ) |
Cross Reference | NSN 5340-01-236-3519
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1175250-3 | 05824 | AEROJET ROCKETDYNE, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-01-236-3519
Related Products | NSN 5340-01-236-3519
Technical Data | NSN 5340-01-236-3519
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 7075 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-A-225/9 FED SPEC SINGLE MATERIAL RESPONSE OR QQ-A-250/12 FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | CHEMICAL CONVERSION COATED OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-C-5541,CLASS 3 MIL SPEC SINGLE TREATMENT RESPONSE OVERALL |
| III APPLICATION/FUNCTION | CLAMP FOR TORUS SUBASSEMBLY ON PEACEKEEPER MISSILE,LGM-118A |
| MANUFACTURERS CODE | 05824 |
| DESIGN CONTROL REFERENCE | 1175250-3 |
