Product Details | MOUNTING BRACKET
5340-01-197-5470 A bracket of various shapes (other than angle), designed to be attached to a supporting surface for the specific purpose of positioning, aligning and/or supporting another item. Excludes BRACE (as modified); BRACKET, ANGLE; and BRACKET, DOUBLE ANGLE. See also BRACKET (1), ELECTRICAL CONNECTOR; BRACKET, FIRE EXTINGUISHER; BRACKET, SOLENOID; BRACKET, TRACK, SLIDING DOOR; and RETAINER (as modified).20510050018Guns, through 30mm10100026Guns, over 30mm up to 75mm1420000053400020Hardware, Commercial
Part Alternates: 12340364, 5340PL0835584, 5583550, 5340-01-197-5470, 01-197-5470, 5340011975470, 011975470
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 22 DEC 1984 | 01-197-5470 | 38089 ( BRACKET, MOUNTING ) |
