Product Details | BUTT HINGE
5340-01-120-4140 A hinge usually with rectangularly shaped leaves. The dimension parallel to the hinge pin must be greater than the dimension transverse to the hinge pin. It may have a tension coil spring at its pivot(s) for closing action, and may have a third member between its pivot(s) to permit the door, or the like, to swing in an arc from either side.
Part Alternates: MS202574700, MS20257-4-700, 114S2905371, 114S2905-371, 5340-01-120-4140, 01-120-4140, 5340011204140, 011204140
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 18 OCT 1981 | 01-120-4140 | 22894 ( HINGE, BUTT ) |
Drawings & Photos | NSN 5340-01-120-4140
Demand History | NSN 5340-01-120-4140
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5340-01-120-4140 | 2018-09-255 | 10 | United States |
| 5340-01-120-4140 | 2008-01-24 | 210 | DIBBS |
| 114S2905371 | 2007-03-64 | 5 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-01-120-4140
Related Products | NSN 5340-01-120-4140
Technical Data | NSN 5340-01-120-4140
| Characteristic | Specifications |
|---|---|
| MATERIAL AND LOCATION | ALUMINUM ALLOY, QQ-A-250/8, ALLOY 5052, H24 BODY OR ALUMINUM ALLOY, QQ-A-250/8, ALLOY 5052, H34 BODY |
| STYLE DESIGNATOR | 18 BUTT |
| OVERALL LENGTH | 7.000 INCHES NOMINAL |
| MATERIAL THICKNESS | 0.040 INCHES NOMINAL |
| PIN DIAMETER | 0.090 INCHES NOMINAL |
| PIN CENTER TO BODY EDGE DISTANCE | 0.750 INCHES NOMINAL |
| HINGE MOUNTING TYPE | FULL SURFACE |
| REVERSIBLE FEATURE | NOT INCLUDED |
| PIN REMOVABILITY | NONREMOVABLE |
| KNUCKLE TYPE | FRICTION |
| KNUCKLE QUANTITY | 14 |
| PERFORMANCE TYPE | NOT RATED |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS20257-4-700 |
