Product Details | CATCH STRIKE
5340-01-070-3209 A platelike item designed to be fastened to a door, door jamb, or the like, for the purpose of receiving the mating pin, plunger or bolt, of a lock, latch, or catch. See also RECEPTACLE, FRICTION CATCH STUD.20210050018Guns, through 30mm53400020Hardware, Commerical
Part Alternates: 12012278-1, 8449334 , 5340-01-070-3209, 01-070-3209, 5340010703209, 120122781, 010703209
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 10 JAN 1979 | 01-070-3209 | 20251 ( STRIKE, CATCH ) |
Drawings & Photos | NSN 5340-01-070-3209
Demand History | NSN 5340-01-070-3209
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 8449334 | 2011-11-334 | 1 | us |
| 8449334 | 2011-11-334 | 3 | us |
Cross Reference | NSN 5340-01-070-3209
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12012278-1 | 19204 | ARMY UNITED STATES DEPARTMENT OF THE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-01-070-3209
Related Products | NSN 5340-01-070-3209
Technical Data | NSN 5340-01-070-3209
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 304 OVERALL |
| OVERALL LENGTH | 4.500 INCHES NOMINAL |
| OVERALL WIDTH | 1.060 INCHES NOMINAL |
| OPENING WIDTH | 0.560 INCHES NOMINAL |
| OPENING LENGTH | 1.750 INCHES NOMINAL |
| FIRST SURFACE HOLE SIZE | 0.562 INCHES NOMINAL |
| HEIGHT | 2.000 INCHES NOMINAL |
| FIRST SURFACE HOLE QUANTITY | 2 |
| MOUNTING FACILITY | UNTHREADED HOLE |
| MANUFACTURERS CODE | 19204 |
| DESIGN CONTROL REFERENCE | 12012278-1 |
Restrictions/Controls & Freight Information | NSN 5340-01-070-3209
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 156600 | PLASTIC/RUBBER ARTICLE VIZ: |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 684 | unknown |
| Originating Activity Code | BF | U.S. Army Armament and Chemical Acquisition and Logistics Activity Rock Island, IL 61299-6000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
