NSN 5340-01-067-7215 ST9M58513, ST9M585-13, TL10014113
Product Details | CLAMPING CATCH
5340-01-067-7215 A positive fastening device consisting of a mountable base with an extended loop, claw, or the like. It may include a catch strike and mounting hardware for its complete installation on flat surfaces. The loop, claw, or the like can be manually engaged or disengaged readily for the purpose of securing the mating sections of a suitcase, locker-trunk, shipping and storage container, prefabricated building, tool chest or the like. Excludes CATCH, ELBOW; CATCH, FLUSH; CATCH, FRICTION; and LATCH or LOCK (as modified).
Part Alternates: ST9M58513, ST9M585-13, TL10014113, TL10014-113, 5340-01-067-7215, 01-067-7215, 5340010677215, 010677215
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 05-NOV-78 | 01-067-7215 | 26525 ( CATCH, CLAMPING ) |
Cross Reference | NSN 5340-01-067-7215
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| A40002-19 | 52607 | ACTRON MANUFACTURING, INC. |
| H2341-11 | 83014 | HARTWELL CORPORATION |
| ST9M416-13 | 76301 | BOEING COMPANY, THE DBA BOEING |
| ST9M585-23 | 76301 | BOEING COMPANY, THE DBA BOEING |
| TL10001-113 | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| TL10014-213 | 29372 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5340-01-067-7215
Technical Data | NSN 5340-01-067-7215
| Characteristic | Specifications |
|---|---|
| SURFACE TREATMENT | ANODIZE HANDLE PASSIVATE HOOK ANODIZE HOUSING PASSIVATE LINK PASSIVATE PIN PASSIVATE RETAINER PASSIVATE SCREW CADMIUM AND CHROMATE SPRING PASSIVATE YOKE |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-A-8625,TYPE 3 MIL SPEC SINGLE TREATMENT RESPONSE HANDLE QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE HOOK MIL-A-8625,TYPE 3 MIL SPEC SINGLE TREATMENT RESPONSE HOUSING QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE LINK QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE PIN QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE RETAINER QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE SCREW QQ-P-416,TYPE 2,CLASS 2 FED SPEC ALL TREATMENT RESPONSES SPRING QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE YOKE |
| OVERALL LENGTH | 6.470 INCHES MINIMUM AND 6.530 INCHES MAXIMUM |
| OVERALL WIDTH | 0.985 INCHES MINIMUM AND 1.010 INCHES MAXIMUM |
| SPECIAL FEATURES | MOLD LINE RADIUS 22.50 IN,MOLD LINE LEVEL ANGLE 0 DEGREES |
| MANUFACTURERS CODE | 29372 |
| DESIGN CONTROL REFERENCE | TL10014-113 |
Restrictions/Controls & Freight Information | NSN 5340-01-067-7215
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
