NSN 5340-00-672-0474 114584, 00-672-0474, 006720474
Product Details | HELICAL COMPRESSION SPRING RETAINER
5340-00-672-0474 A cylindrical item specifically designed to fit over the end of, and completely encase the spring. The open end is usually flanged, the opposite end may be closed or have an orifice to accommodate a guide, plunger, or the like. It is used to position the spring and restrain lateral motion. It may provide a seat for the spring. Excludes HOLDER, SPRING.
Part Alternates: 114584, 5340-00-672-0474, 00-672-0474, 5340006720474, 006720474
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-672-0474 | 24327 ( RETAINER, HELICAL COMPRESSION SPRING ) |
Drawings & Photos | NSN 5340-00-672-0474
Demand History | NSN 5340-00-672-0474
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 114584 | 2024-02-37 | 6 | DIBBS |
| 114584 | 2023-01-08 | 8 | DIBBS |
| 5340-00-672-0474 | 2018-08-219 | 5 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5340-00-672-0474
Related Products | NSN 5340-00-672-0474
Technical Data | NSN 5340-00-672-0474
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL, MIL-S-7720, COMP 303S, COND B OR CRES AMS5366 |
| MATERIAL HARDNESS RATING | NOT RATED |
| CASEHARDENING INDICATOR | NOT CASEHARDENED |
| STYLE DESIGNATOR | C4 IRREGULAR |
| OVERALL HEIGHT | 2.650 INCHES NOMINAL |
| MOUNTING HOLE DIAMETER | 0.095 INCHES NOMINAL |
| BODY OUTSIDE DIAMETER | 0.620 INCHES NOMINAL |
| BODY INSIDE DIAMETER | 0.375 INCHES NOMINAL |
| SPECIAL FEATURES | 0.190-32 NF-3B THD BY 0.380 IN. LG APPROX ON ONE END |
| MANUFACTURERS CODE | 70210 |
| DESIGN CONTROL REFERENCE | 114584 |
Restrictions/Controls & Freight Information | NSN 5340-00-672-0474
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5340-00-672-0474
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | TP | SX:"TEMPERATURE AND PRESSURE CONTROLS, AIRCRAFT" |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
