NSN 5340-00-286-9430 MS21919G14, MS21919WG14, TA1718WD SERIES
Product Details | LOOP CLAMP
5340-00-286-9430 A clamp designed to surround other item(s) such as cable(s), conduit(s), pipe(s), hose(s), or tube(s), and to fasten together or to another object or structure. Includes straight flexible items. For items specifically designed to clamp a hose to a connection to prevent leakage, see CLAMP, HOSE. See also HANGER, PIPE and CLIP, SPRING TENSION. For retaining straps with a bridge, see STRAP, RETAINING. Excludes CLAMP, ELECTRICAL; BAND, RETAINING; CLAMP (1), C; BRACKET PIPE.202534000005342000000
Part Alternates: MS21919G14, MS21919WG14, TA1718WD SERIES, TA1718WDSERIES, JM44LC SERIES, JM44LCSERIES, 5340-00-286-9430, 00-286-9430, 5340002869430, 002869430
Hardware and Abrasives | Hardware, Commercial
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-286-9430 | 17532 ( CLAMP, LOOP ) |
Drawings & Photos | NSN 5340-00-286-9430
Demand History | NSN 5340-00-286-9430
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5340-00-286-9430 | 2022-03-82 | 981 | DIBBS |
| MS21919WG14 | 2017-04-110 | 60 | United States |
| MS21919WG14 | 2012-05-135 | 2 | Canada |
| MS21919WG14 | 2011-01-07 | 500 | United States |
| MS21919WG14 | 2010-12-350 | 16 | US |
| 5340-00-286-9430 | 2009-12-358 | 271 | DIBBS |
| 5340-00-286-9430 | 2009-07-187 | 5496 | DIBBS |
| 5340-00-286-9430 | 2009-07-183 | 5000 | DIBBS |
| 5340-00-286-9430 | 2009-06-153 | 4852 | DIBBS |
| 5340-00-286-9430 | 2009-05-148 | 5000 | DIBBS |
| 5340-00-286-9430 | 2009-01-02 | 769 | DIBBS |
| 5340-00-286-9430 | 2008-09-270 | 629 | DIBBS |
| 5340-00-286-9430 | 2008-09-253 | 632 | DIBBS |
| 5340-00-286-9430 | 2008-07-189 | 866 | DIBBS |
| 5340-00-286-9430 | 2008-02-36 | 223 | DIBBS |
Cross Reference | NSN 5340-00-286-9430
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| JM44LC SERIES | 22175 | J & M PRODUCTS, INC. |
| MS21919G14 | 86896 | SCHENUIT INDUSTRIES INC |
| MS21919G14 | D9182 | BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT |
| MS21919WG14 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| TA1718WD SERIES | 84971 | KIRKHILL-TA CO. DBA TA DIVISION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5340-00-286-9430
Technical Data | NSN 5340-00-286-9430
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 1008 OR STEEL COMP 1009 OR STEEL COMP 1015 OR STEEL COMP 1018 OR STEEL COMP 1020 BAND RUBBER CHLOROPRENE CLASS CR CUSHION |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 3209 ASSN STD SINGLE MATERIAL RESPONSE CUSHION |
| SURFACE TREATMENT | CADMIUM BAND |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416 TY 1 CL 2 FED SPEC SINGLE TREATMENT RESPONSE BAND |
| STYLE DESIGNATOR | A5 OFFSET MOUNT |
| OVERALL WIDTH | 0.490 INCHES MINIMUM AND 0.510 INCHES MAXIMUM |
| MATERIAL THICKNESS | 0.032 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN LOOP AND MOUNTING HOLE | 0.874 INCHES MINIMUM AND 0.904 INCHES MAXIMUM |
| DISTANCE FROM LOOP CENTER TO TONGUE END | 1.107 INCHES NOMINAL |
| LOOP INSIDE DIAMETER | 0.860 INCHES MINIMUM AND 0.890 INCHES MAXIMUM |
| TONGUE HOLE TYPE | ROUND, UNTHREADED |
| DIAMETER | 0.204 INCHES NOMINAL |
| CUSHIONING ENVIRONMENTAL PROTECTION | WEATHER RESISTANT |
| SPECIAL FEATURES | WEDGE TYPE CUSHION CONSTRUCTION |
| NONDEFINITIVE SPEC/STD DATA | 4 TYPE AND B CLASS |
| DEPARTURE FROM CITED DESIGNATOR | AS MODIFIED BY SPECIAL FEATURES |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS21919WG14 |
Restrictions/Controls & Freight Information | NSN 5340-00-286-9430
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
