NSN 5330-01-502-8269 10472, 10-472, 30-003C-A IT 41
Product Details | PLAIN ENCASED SEAL
5330-01-502-8269 A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes PACKING WITH RETAINER.
Part Alternates: 10472, 10-472, 30-003C-A IT 41, 30003CAIT41, 30-018 IT 8, 30018IT8, 30-044 IT 8, 30044IT8, 472409, 5330-01-502-8269, 01-502-8269, 5330015028269, 015028269
Hardware and Abrasives | Packing and Gasket Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 21 NOV 2002 | 01-502-8269 | 04214 ( SEAL, PLAIN ENCASED ) |
Drawings & Photos | NSN 5330-01-502-8269
Demand History | NSN 5330-01-502-8269
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 10-472 | 2024-09-270 | 105 | DIBBS |
| 30-003C-A IT 41 | 2024-09-270 | 105 | DIBBS |
| 30-018 IT 8 | 2024-09-270 | 105 | DIBBS |
| 30-044 IT 8 | 2024-09-270 | 105 | DIBBS |
| 5330-01-502-8269 | 2014-05-128 | 80 | DIBBS |
| 5330-01-502-8269 | 2012-10-277 | 16 | DIBBS |
| 5330-01-502-8269 | 2008-07-196 | 20 | DIBBS |
Cross Reference | NSN 5330-01-502-8269
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5330-01-502-8269
Technical Data | NSN 5330-01-502-8269
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL CORROSION RESISTING CASE RUBBER BUTADIENE-ACRYLONITRILE CLASS NBR SEALING ELEMENT A |
| HARDNESS RATING | 60.0 SHORE DUROMETER A MINIMUM AND 80.0 SHORE DUROMETER A MAXIMUM SEALING ELEMENT A |
| CASE STYLE | 1 SQUARE |
| SEALING ELEMENT STYLE | 2 VERTICAL |
| SEAL WIDTH | 0.375 INCHES NOMINAL |
| ACCOMMODATED SHAFT DIAMETER | 2.125 INCHES NOMINAL |
| HOUSING BORE DIAMETER | 3.189 INCHES NOMINAL |
| SPECIAL FEATURES | SEAL,NATIONAL 472409 |
| III END ITEM IDENTIFICATION | GIMBLE HOUSING ASSY,STERN DRIVE |
Restrictions/Controls & Freight Information | NSN 5330-01-502-8269
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194090 | WASHERS/SEALS |
| Less than car load rating | ||
| Less than truck load rating | S | 60.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5330-01-502-8269
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
