NSN 5330-00-618-3956 509, 00-618-3956, 006183956
Product Details | CLOTH INSERT SOLID RUBBER SHEET
5330-00-618-3956 A sheet material consisting of a vulcanized elastomeric material inclosing a sheet of nonmetallic cloth, or of alternate layers of nonmetallic cloth and elastomer with elastomeric faces. The elastomer is the primary substance and the nonmetallic cloth is inserted for stiffness and/or to prevent deformation under stress in its plane. It may be provided flat or in rolls. It is normally used as a gasket material. Sheets are limited to widths greater than 6 inches (152.4 mm). See also CLOTH, COATED; CLOTH LAMINATED; and RUBBER SHEET, SOLID.
Part Alternates: 509, 5330-00-618-3956, 00-618-3956, 5330006183956, 006183956
Hardware and Abrasives | Packing and Gasket Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-618-3956 | 21147 ( RUBBER SHEET, SOLID, CLOTH INSERT ) |
Cross Reference | NSN 5330-00-618-3956
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 509 | 61463 | CHEMTURA CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5330-00-618-3956
Technical Data | NSN 5330-00-618-3956
| Characteristic | Specifications |
|---|---|
| MATERIAL | RUBBER, SYNTHETIC |
| STRENGTHENING FEATURE | INSERT |
| INSERT QUANTITY | 4 |
| STRENGTHENING FEATURE MATERIAL | CLOTH, COTTON |
| NONMETALLIC HARDNESS RATING | NOT RATED |
| MINIMUM TENSILE STRENGTH | NOT RATED |
| SURFACE CONDITION | SMOOTH |
| LENGTH | 180.000 INCHES NOMINAL |
| WIDTH | 46.000 INCHES NOMINAL |
| THICKNESS | 0.250 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5330-00-618-3956
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
