NSN 5310-01-122-5815 MS1782812C, MS17828-12C, MS1782816C
Product Details | HEXAGON SELF-LOCKING NUT
5310-01-122-5815 A nut having a flat bottom and 6 sides. An integral feature is incorporated for locking on the threads of a mating member. Excludes NUT (1), SELF-LOCKING, CAP.
Part Alternates: MS1782812C, MS17828-12C, MS1782816C, MS17828-16C, MILN25027, MIL-N-25027, MIL-N-25027/MS 17828, MILN25027MS17828, 000.750-10UNC-3B, 00075010UNC3B, 001.000-08ONC-3B, 00100008ONC3B, 1504-50 PIECE 7, 150450PIECE7, 4497645PC7, 5310-01-122-5815, 01-122-5815, 5310011225815, 011225815
Hardware and Abrasives | Nuts and Washers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 02 NOV 1984 | 01-122-5815 | 05277 ( NUT, SELF-LOCKING, HEXAGON ) |
Drawings & Photos | NSN 5310-01-122-5815
Demand History | NSN 5310-01-122-5815
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS1782812C | 2024-10-299 | 4 | United States |
| MILN25027 | 2023-08-236 | 54 | US |
| MS1782812C | 2023-08-228 | 560 | us |
| MILN25027 | 2020-09-262 | 156 | US |
| MS1782812C | 2019-07-182 | 5 | IT |
| MS1782812C | 2019-07-182 | 25 | IT |
| MS1782812C | 2016-04-116 | 376 | United States |
| MS1782812C | 2015-01-26 | 3304 | United States |
| MS1782812C | 2012-10-285 | 88 | United States |
| MS1782812C | 2012-10-278 | 4 | United States |
| MILN25027 | 2012-06-157 | 16 | United States |
| MILN25027 | 2012-05-139 | 15 | United States |
| MILN25027 | 2011-09-265 | 28 | US |
| MILN25027 | 2011-09-264 | 25 | Canada |
| MILN25027 | 2011-02-49 | 5 | US |
| MILN25027 | 2011-02-49 | 10 | US |
| MILN25027 | 2011-02-49 | 40 | US |
| MILN25027 | 2010-06-181 | 50 | United States |
| MILN25027 | 2010-04-111 | 5000 | US |
| MILN25027 | 2009-11-321 | 560 | US |
| MILN25027 | 2009-10-281 | 8 | Canada |
| MILN25027 | 2008-09-270 | 50 | Italy |
| MS1782812C | 2008-02-36 | 1000 | United States |
Cross Reference | NSN 5310-01-122-5815
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 000.750-10UNC-3B | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 001.000-08ONC-3B | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 1504-50 PIECE 7 | 43689 | HUNTINGTON INGALLS INCORPORATED DIV NEWPORT NEWS |
| 4497645PC7 | 43689 | HUNTINGTON INGALLS INCORPORATED DIV NEWPORT NEWS |
| MIL-N-25027 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-N-25027/MS 17828 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| MS17828-12C | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS17828-16C | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5310-01-122-5815
Related Products | NSN 5310-01-122-5815
Technical Data | NSN 5310-01-122-5815
| Characteristic | Specifications |
|---|---|
| THREAD SERIES | UNC |
| NOMINAL THREAD SIZE | 0.750 INCHES |
| THREAD QUANTITY PER INCH | 10 |
| THREAD CLASS | 3B |
| THREAD DIRECTION | RIGHT-HAND |
| MATERIAL | PLASTIC POLYAMIDE LOCKING INSERT NICKEL ALLOY NUT |
| BEARING SURFACE TYPE | WASHER FACED |
| LOCKING FEATURE | PREVAILING TORQUE WITH NONMETALLIC INSERT |
| DEPARTURE FROM CITED DOCUMENT | MATERIAL WILL BE IN ACCORDANCE WITH SHIPS PARTS CONTROL CENTER ACTIVITY HX QUALITY CONTROL,MANUFACTURING AND TESTING SPECIFICATIONS |
| CRITICALITY CODE JUSTIFICATION | ZZZW |
| MANUFACTURERS CODE | 96906 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS17828-12C |
Restrictions/Controls & Freight Information | NSN 5310-01-122-5815
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5310-01-122-5815
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 1H | Consumable material assigned to NAVICP MECH for inventory management Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | X3 | Nuclear Reactor Plant (NRP) material under the technical cognizance of the NAVSEA 08 special designed, manufactured and/or treated for use in a NRP or controls thereof. This category includes all other NRP items which are not coded X2 or X4. |
| Issue Repair, or Requisition | BL | Submit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipments. |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | M | Medium Demand Velocity Items (consumables) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
5 EA : Each |
