NSN 5310-01-044-6570 M45938/1-9C, M4593819C, M45938-1-9C

Product Details | CLINCH PLAIN NUT

5310-01-044-6570 A nut having a sleeve portion on its under side, which can be crimped or clinched to hold the item in place when inserted in a hole.

Part Alternates: M45938/1-9C, M4593819C, M45938-1-9C, NASM45938/1, NASM459381, NGX1712442, NGX17124-42, CLS6322, CLS-632-2, CLS6-32-2, CLS632-2, DRA45659, PEMCLS6322, PEMCLS632-2, MIL-N-45938/1-9C, MILN4593819C, 592-007-011, 021708, 02170-8, 0N08181516, 0N081815-16, 100018, 10001-8, 18004CSS0632, 18004C-SS-0632, 218752, 21875-2, 25462405, 2546240-5, 26057678, 2605767-8, 32262127, 322621-27, 33C817015, 33C817-015, 37163611, 371636-11, 40010145, 4001014-5, 410817-602, 501311, 5013-11, 50SWX6324, 50SWX-632-4, 600006-639, 625917, 632NKS0056, 74443063011, 808149, 80814-9, 9063541, 99028811, 990288-11, 5310-01-044-6570, 01-044-6570, 5310010446570, 010446570, 443063011, 410817602, 592007011, 600006639

Hardware and Abrasives | Nuts and Washers

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
53	18 JUL 1977	01-044-6570	01860 ( NUT, PLAIN, CLINCH )

Drawings & Photos | NSN 5310-01-044-6570

Part Number	Request Date	QTY	Origin
5310-01-044-6570	2023-04-110	40	US
M4593819C	2022-06-180	2000	United States
M4593819C	2022-03-66	16	US
CLS6322	2022-02-55	10500	United States
NASM459381	2018-06-171	20	US
5310-01-044-6570	2017-09-262	10	United States
5310-01-044-6570	2017-08-222	25	United States
NASM459381	2017-06-173	100	United States
M4593819C	2017-03-76	10	US
CLS6322	2015-08-226	48	United States
CLS6322	2014-09-259	108	United States
CLS6322	2014-02-38	9360	US
5310-01-044-6570	2013-08-227	45	US
CLS6322	2012-09-269	500	US
M4593819C	2011-11-332	132	US
M4593819C	2011-09-255	500	AE
MILN4593819C	2011-08-238	10	US
MILN4593819C	2011-08-238	12	US
NASM459381	2011-06-161	5	US
NASM459381	2011-06-161	15	US
NASM459381	2011-06-161	25	US
NASM459381	2011-06-161	50	US
M4593819C	2011-05-130	1680	Canada
CLS6322	2011-01-27	70	United States
5310-01-044-6570	2010-03-70	150	India
PEMCLS6322	2009-07-194	125	United States
CLS6322	2009-06-156	20	US
5310-01-044-6570	2009-05-146	300	United States
CLS6322	2009-04-111	200	US
CLS6322	2009-02-55	60	US
CLS6322	2008-08-233	500	United Kingdom
5310-01-044-6570	2008-08-228	10	US
CLS6322	2008-07-198	5000	China
CLS6322	2008-06-162	140	Canada
CLS6322	2008-03-66	20000	US

Cross Reference | NSN 5310-01-044-6570

Part Number	Cage Code	Manufacturer
02170-8	98853	HAMILTON STANDARD ELECTRONICS SYSTEMS INC
0N081815-16	98230	NATIONAL SECURITY AGENCY
10001-8	12909	CARDION INC
10001-8	20284	TARGET CORPORATION DBA TARGET
18004C-SS-0632	06540	NEW HAVEN MFG CORP AMATOM ELECTRONIC HARDWARE DIV
21875-2	30377	SMITHS AEROSPACE INC. ELECTRONIC SYSTEMS-GRAND RAPIDS
2546240-5	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
2605767-8	06424	ALLIANT TECHSYSTEMS OPERATIONS LLC DIV DEFENSE ELECTRONIC SYSTEMS
322621-27	97525	TRANSICO INC. DBA EECO SWITCH
33C817-015	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
371636-11	3B150	RAYTHEON TECHNICAL SERVICES COMPANY LLC
371636-11	49956	RAYTHEON COMPANY DBA RAYTHEON
4001014-5	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
410817-602	96214	RAYTHEON COMPANY DBA RAYTHEON
443063011	94474	RUDOLPH RESEARCH
5013-11	82340	EDO CORPORATION DIV DEFENSE SYSTEMS
50SWX-632-4	56878	SPS TECHNOLOGIES, LLC DBA AEROSPACE DIVISION
592-007-011	57057	NAVCOM DEFENSE ELECTRONICS, INC.
600006-639	13626	ALCATEL NETWORK SYSTEMS INC
625917	13626	ALCATEL NETWORK SYSTEMS INC
632NKS-(0.056)	86577	PRECISION METAL PRODUCTS CO
74443063011	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
80814-9	96214	RAYTHEON COMPANY DBA RAYTHEON
9063541	18876	U S ARMY AVIATION AND MISSILE COMMAND
990288-11	00752	EDO CORPORATION DIV EDO CORPORATION AP&T
CLS-632-2	46384	PENN ENGINEERING & MANUFACTURING CORP.
CLS6-32-2	05394	PEM MACHINE AND TOOL CO INC
CLS632-2	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
DRA45659	09975	UNISYS CORPORATION
M45938-1-9C	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
M45938/1-9C	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MIL-N-45938/1-9C	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
NASM45938/1	80205	NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES
NGX17124-42	80020	NAVAL AIR WARFARE CENTER AIRCRAFT DIVISION CODE 4.8.8.0.0.B BLDG 148-2
PEMCLS632-2	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5310-01-044-6570

Compare

Related Products | NSN 5310-01-044-6570

5310-01-044-6571, 5310-01-044-6572, 5310-01-044-6573, 5310-01-044-6577, 5310-01-044-6579

Technical Data | NSN 5310-01-044-6570

Characteristic	Specifications
THREAD SERIES	UNC
NOMINAL THREAD SIZE	0.138 INCHES
THREAD QUANTITY PER INCH	32
THREAD CLASS	2B
THREAD DIRECTION	RIGHT-HAND
MATERIAL	STEEL CORROSION RESISTING OVERALL
HARDNESS RATING	NOT RATED
NUT STYLE	A57 CLINCH
PILOT DIAMETER	0.182 INCHES MINIMUM AND 0.185 INCHES MAXIMUM
PILOT LENGTH	0.049 INCHES MINIMUM AND 0.054 INCHES MAXIMUM
NUT DIAMETER	0.266 INCHES MINIMUM AND 0.296 INCHES MAXIMUM
NUT HEIGHT	0.096 INCHES MINIMUM AND 0.131 INCHES MAXIMUM
TEMP RATING	NOT RATED
MANUFACTURERS CODE	81349
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	M45938/1-9C

Restrictions/Controls & Freight Information | NSN 5310-01-044-6570

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:	0	Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)

Category	Code	Description
NMF Description	093486	BOLTS,NUTS OR SCREWS, NOI (SUB 3)
Less than car load rating
Less than truck load rating	W	Rating Variable
Water commodity Code	573	unknown
Originating Activity Code	KZ	Defense Supply Center Philadelphia Philadelphia, PA 19101
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	B	Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 5310-01-044-6570

Category	Code	Description
Materiel Category and Inventory Manager	T	Industrial Supplies (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	0	Medical Materiel
Weapons Systems/End Item or Homogeneous Group	00	DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price Validation	N	The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM. The price has not been analyzed or reviewed for accuracy. ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Materiel Management Aggregation Code	SX	SX:AF SICA RESIDUAL MMAC-OC-ALC
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative

Category	Code	Description
Stores Account Code	1	Marine Corps Stock Fund Account Item.
Combat Essentiality Code	2	Non-Critical Repair Part. Repair parts or major components whose failure in an end item will not render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency, and which do not fit the definition of Code 3 or 4 items.
Materiel Management Code	B	All CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code	2	ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DM	U.S. Marine Corps
Service Organization	M	U.S. Marine Corps
Reparability	Z	Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Special Material Content	9	Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
