NSN 5307-01-212-0214 7136961, 713696-1, 01-212-0214
Product Details | RECESSED STUD
5307-01-212-0214 A headless fastener not exceeding twelve inches (304.8 mm) in length, threaded externally on both ends with threads of the same nominal diameter. One end or both ends may have a point. The unthreaded section may have more than one diameter, none of which may be greater than the maximum major thread diameter. It may be thread relieved. Excludes items with taper threads.
Part Alternates: 7136961, 713696-1, 5307-01-212-0214, 01-212-0214, 5307012120214, 012120214
Hardware and Abrasives | Studs
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 05 JUL 1985 | 01-212-0214 | 15945 ( STUD, RECESSED ) |
Demand History | NSN 5307-01-212-0214
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5307-01-212-0214 | 2020-10-281 | 23 | DIBBS |
| 5307-01-212-0214 | 2020-03-75 | 3 | DIBBS |
Cross Reference | NSN 5307-01-212-0214
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 713696-1 | 99167 | HAMILTON SUNDSTRAND CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5307-01-212-0214
Related Products | NSN 5307-01-212-0214
Technical Data | NSN 5307-01-212-0214
| Characteristic | Specifications |
|---|---|
| THREAD DIRECTION | RIGHT-HAND NUT THREAD |
| STYLE DESIGNATOR | RECESSED |
| NOMINAL THREAD SIZE | 0.312 INCHES STUD THREAD |
| HARDNESS RATING | 40.0 ROCKWELL C MINIMUM AND 45.0 ROCKWELL C MAXIMUM |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416,TY2,CL 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| THREAD CLASS | 3A NUT THREAD |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 6322 ASSN STD 1ST MATERIAL RESPONSE OR AMS 6382 ASSN STD 2ND MATERIAL RESPONSE OR AMS 6415 ASSN STD 3RD MATERIAL RESPONSE |
| THREAD LENGTH | 0.619 INCHES MINIMUM AND 0.639 INCHES MAXIMUM STUD THREAD |
| NOMINAL THREAD SIZE | 0.312 INCHES NUT THREAD |
| OVERALL LENGTH | 1.535 INCHES MINIMUM AND 1.555 INCHES MAXIMUM |
| SURFACE FINISH | 32.0 MICROINCHES STUD THD |
| SURFACE FINISH | 32.0 MICROINCHES NUT THD |
| LENGTH OF RECESSED PORTION OF SHANK | 0.280 INCHES NOMINAL |
| THREAD QUANTITY PER INCH | 24 NUT THREAD |
| THREAD DIRECTION | RIGHT-HAND STUD THREAD |
| SURFACE TREATMENT | CADMIUM AND CHROMATE OVERALL |
| THREAD PITCH DIAMETERS | +0.2810 TO 0.2825 INCHES STUD THREAD |
| SURFACE FINISH | 63.0 MICROINCHES UNDERCUTS |
| THREAD SERIES DESIGNATOR | UNJF NUT THREAD |
| SPECIAL FEATURES | UNTHREADED SECTION DIA. 0.3125 INCH |
| DIAMETER OF RECESSED PORTION OF SHANK | 0.221 INCHES MINIMUM AND 0.231 INCHES MAXIMUM |
| THREAD SERIES DESIGNATOR | UNS STUD THREAD |
| THREAD LENGTH | 0.432 INCHES MINIMUM AND 0.452 INCHES MAXIMUM NUT THREAD |
| THREAD QUANTITY PER INCH | 18 STUD THREAD |
| MATERIAL | STEEL COMP 8740 OR STEEL COMP 4140 OR STEEL COMP 4340 |
Restrictions/Controls & Freight Information | NSN 5307-01-212-0214
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 573 | unknown |
| Originating Activity Code | KH | Defense Industrial Supply Center Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5307-01-212-0214
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | E | The current standard price is an estimated price.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
