NSN 5306-01-532-6410 NAS564C23, 01-532-6410, 015326410
Product Details | MACHINE BOLT
5306-01-532-6410 An externally threaded fastener designed for insertion through holes in assembled parts and normally intended to be tightened or released by torquing a nut. The threaded and unthreaded portions are both of one nominal diameter of 0.190 inch (5 mm) or larger. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. For items having a grip length portion machined to a tolerance of 0.0015 inch (0.038 mm) or less, BOLT, SHEAR. See also SCREW, CAP, HEXAGON HEAD and SCREW, MACHINE.
Part Alternates: NAS564C23, 5306-01-532-6410, 01-532-6410, 5306015326410, 015326410
Hardware and Abrasives | Bolts
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
53 | 15 AUG 2005 | 01-532-6410 | 01847 ( BOLT, MACHINE ) |
Demand History | NSN 5306-01-532-6410
Part Number | Request Date | QTY | Origin |
---|---|---|---|
5306-01-532-6410 | 2024-11-310 | 5 | DIBBS |
5306-01-532-6410 | 2024-03-64 | 3 | DIBBS |
NAS564C23 | 2012-05-142 | 4 | United States |
NAS564C23 | 2011-04-109 | 12 | US |
NAS564C23 | 2011-01-28 | 12 | United States |
Cross Reference | NSN 5306-01-532-6410
Part Number | Cage Code | Manufacturer |
---|---|---|
NAS564C23 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
Request a Quote
What Our Customers Say
Compare
Related Products | NSN 5306-01-532-6410
Technical Data | NSN 5306-01-532-6410
Characteristic | Specifications |
---|---|
THREAD SERIES DESIGNATOR | UNJF |
NOMINAL THREAD DIAMETER | 0.230 INCHES |
THREAD QUANTITY PER INCH | 28 |
THREAD CLASS | 3A |
THREAD DIRECTION | RIGHT-HAND |
THREAD LENGTH | 0.659 INCHES NOMINAL |
FASTENER LENGTH | 0.719 INCHES NOMINAL |
MATERIAL | STEEL OVERALL |
SURFACE TREATMENT | CADMIUM OVERALL |
HEAD STYLE | C1 HEXAGON |
HEAD HEIGHT | 0.219 INCHES NOMINAL |
WIDTH BETWEEN FLATS | 0.438 INCHES NOMINAL |
HOLE CONFIGURATION STYLE | E8 HEXAGON PERPENDICULAR |
HOLE TYPE | DRILLED |
HOLE QUANTITY | 6 |
HOLE DIAMETER | 0.070 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 5306-01-532-6410
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
