NSN 5306-00-953-2379 205364P20, 00-953-2379, 009532379
Product Details | EXTERNALLY RELIEVED BODY BOLT
5306-00-953-2379 An externally threaded fastener whose threaded portion is of one nominal diameter, and whose unthreaded portion has been machined or ground in one or more places or over its entire length to a maximum diameter less than the minimum pitch diameter of the thread (excludes undercuts for thread relief). It is No. 10 (0.190 IN.) (5 mm) or larger in size and has a head which is not designed to be held or driven with an inserted driver or designed for rotation by the thumb and fingers. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, INTERNAL WRENCHING and THUMBSCREW. See also SCREW, EXTERNALLY RELIEVED BODY.
Part Alternates: 205364P20, 5306-00-953-2379, 00-953-2379, 5306009532379, 009532379
Hardware and Abrasives | Bolts
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1962 | 00-953-2379 | 06675 ( BOLT, EXTERNALLY RELIEVED BODY ) |
Cross Reference | NSN 5306-00-953-2379
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 205364P20 | 77445 | UNITED TECHNOLOGIES CORPORATION DBA PRATT WHITNEY-SPARE PARTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5306-00-953-2379
Technical Data | NSN 5306-00-953-2379
| Characteristic | Specifications |
|---|---|
| THREAD SERIES DESIGNATOR | UNF |
| NOMINAL THREAD DIAMETER | 0.4375 INCHES |
| THREAD QUANTITY PER INCH | 20 |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| THREAD LENGTH | 0.690 INCHES NOMINAL |
| FASTENER LENGTH | 2.425 INCHES MINIMUM AND 2.435 INCHES MAXIMUM |
| MATERIAL | STEEL OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 6322 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| HARDNESS RATING | 34.0 ROCKWELL C MINIMUM AND 40.0 ROCKWELL C MAXIMUM OVERALL |
| HEAD DIAMETER | 0.750 INCHES MINIMUM AND 0.770 INCHES MAXIMUM |
| HEAD HEIGHT | 0.090 INCHES MINIMUM AND 0.110 INCHES MAXIMUM |
| EXTERNALLY RELIEVED BODY DIAMETER QUANTITY | 4 |
| FIRST DIAMETER FROM HEAD | 0.358 INCHES MINIMUM AND 0.368 INCHES MAXIMUM |
| SECOND DIAMETER FROM HEAD | 0.4635 INCHES MINIMUM AND 0.4675 INCHES MAXIMUM |
| THIRD DIAMETER FROM HEAD | 0.358 INCHES MINIMUM AND 0.368 INCHES MAXIMUM |
| FOURTH DIAMETER FROM HEAD | 0.434 INCHES MINIMUM AND 0.435 INCHES MAXIMUM |
| FIFTH DIAMETER FROM HEAD | 0.358 INCHES MINIMUM AND 0.368 INCHES MAXIMUM |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FIRST DIAMETER | 0.340 INCHES MINIMUM AND 0.360 INCHES MAXIMUM |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF SECOND DIAMETER | 0.650 INCHES NOMINAL |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF THIRD DIAMETER | 0.820 INCHES MINIMUM AND 0.840 INCHES MAXIMUM |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FOURTH DIAMETER | 0.890 INCHES NOMINAL |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FIFTH DIAMETER | 1.510 INCHES NOMINAL |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF SEVENTH DIAMETER | 1.730 INCHES MINIMUM AND 1.750 INCHES MAXIMUM |
| DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF SIXTH DIAMETER | 1.560 INCHES MINIMUM AND 1.580 INCHES MAXIMUM |
| SEVENTH DIAMETER FROM HEAD | 0.358 INCHES MINIMUM AND 0.368 INCHES MAXIMUM |
| SIXTH DIAMETER FROM HEAD | 0.434 INCHES MINIMUM AND 0.435 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5306-00-953-2379
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5306-00-953-2379
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Z | Navy-owned stocks of defense industrial material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9I | Defense Industrial Supply Center Philadelphia, PA 19111 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
