NSN 5306-00-914-9013 MS27039118, MS27039-1-18 , NAS22118
Product Details | SHEAR BOLT
5306-00-914-9013 A high strength, 160,000 pounds per square inch (1100 megapascals) minimum tensile strength externally threaded fastener designed for use in applications involving great shear stress. The head is designed to accommodate an external wrench or driver. The head is not designed to be held or driven with an inserted driver, nor is it designed for rotation by the thumb and fingers. The unthreaded portion is of specific grip length, plated or unplated, and is machined to a tolerance of one thousandth (0.001) of an inch (0.025 mm) or less of a specific diameter for items one inch (25 mm) or less in diameter. Items over one inch (25 mm) in diameter shall have a tolerance of fifteen ten thousandths (0.0015) of an inch (0.038 mm) or less. The nominal major diameter of the threads shall be at least one thousandth (0.001) of an inch (0.025 mm) below the minimum shank diameter, but not below the minimum major diameter for applicable class of fit, as shown in the Screw Thread Standards, FED STD H28 and/or other nationally recognized standards. A locking feature may be incorporated in the design of the head or threads. See BOLT, MACHINE and BOLT, CLEVIS.
Part Alternates: MS27039118, MS27039-1-18 , NAS22118, NAS221-18 , C0811276, C081-12-76, EWSB2212A76, EWSB22-12A76, 10114676 , 2010922, 5306-00-914-9013, 00-914-9013, 5306009149013, 009149013
Hardware and Abrasives | Bolts
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 08 JUL 1966 | 00-914-9013 | 15903 ( BOLT, SHEAR ) |
Drawings & Photos | NSN 5306-00-914-9013
Demand History | NSN 5306-00-914-9013
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS27039118 | 2023-07-206 | 1000 | US |
| MS27039118 | 2022-02-53 | 500 | US |
| MS27039118 | 2021-02-40 | 30 | United States |
| MS27039118 | 2017-02-46 | 100 | Lebanon |
| 5306-00-914-9013 | 2017-02-46 | 10 | DIBBS |
| MS27039118 | 2015-07-207 | 100 | United States |
| MS27039-1-18 | 2013-12-350 | 100 | Lebanon |
| MS27039-1-18 | 2013-06-170 | 100 | Lebanon |
| 5306-00-914-9013 | 2010-11-323 | 25 | DIBBS |
| 2010922 | 2008-05-140 | 1 | us |
Cross Reference | NSN 5306-00-914-9013
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| C081-12-76 | 06725 | SPS TECHNOLOGIES LLC DBA AIR INDUSTRIES |
| C081-12-76 | 92215 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| EWSB22-12A76 | 56878 | SPS TECHNOLOGIES, LLC DBA AEROSPACE DIVISION |
| EWSB22-12A76 | 80539 | SPS TECHNOLOGIES, LLC DBA AEROSPACE FASTENERS GROUP |
