NSN 5305-01-540-9393 PL565A428H4, 01-540-9393, 015409393
Product Details | SETSCREW
5305-01-540-9393 An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads.
Part Alternates: PL565A428H4, 5305-01-540-9393, 01-540-9393, 5305015409393, 015409393
