Product Details | HEXAGON HEAD CAP SCREW

5305-01-515-4337 An externally threaded fastener designed for insertion into holes in assembled parts, for mating with a preformed internal thread and for tightening or releasing by torquing the head. The threaded and unthreaded portions are both of the same nominal diameter of 0.190 inch (5 mm) or larger. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. The thread length being the controlled dimension, the grip length is not specified. A locking feature may be incorporated in the design of the head or threads. The head is not designed to be held or driven with an inserted driver or by the thumb and fingers. Excludes BOLT,MACHINE; BOLT,EXTERNALLY RELIEVED BODY; BOLT,INTERNAL WRENCHING; and SCREW,CAP,SOCKET HEAD.

Part Alternates: 100056, 10-0056, 5305-01-515-4337, 01-515-4337, 5305015154337, 015154337

Hardware and Abrasives | Screws

Supply Group (FSG) NSN Assign. NIIN
53 25 NOV 2003 01-515-4337

Drawings & Photos | NSN 5305-01-515-4337


Cross Reference | NSN 5305-01-515-4337

Part Number Cage Code Manufacturer
10-0056 62144 PARKER-HANNIFIN CORPORATION DBA RACOR DIVISION

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5305-01-515-4337

Technical Data | NSN 5305-01-515-4337

Characteristic Specifications
NOMINAL THREAD DIAMETER 0.375 INCHES
THREAD QUANTITY PER INCH 16
THREAD DIRECTION RIGHT-HAND
FASTENER LENGTH 2.500 INCHES NOMINAL
MATERIAL STEEL OVERALL
III END ITEM IDENTIFICATION RECIRCULATING BROMINATOR
