NSN 5305-01-506-9566 PS6C6DL01BK, PS6C6D-L01BK, 01-506-9566

5305-01-506-9566 A SCREW, (as modified) to which has been assembled one or more nonremovable washer(s).

Part Alternates: PS6C6DL01BK, PS6C6D-L01BK, 5305-01-506-9566, 01-506-9566, 5305015069566, 015069566

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
53	15 APR 2003	01-506-9566	06660 ( SCREW, ASSEMBLED WASHER )

Part Number	Request Date	QTY	Origin	SBA
PS6C6DL01BK	2008-06-165	2	United States

Part Number	Cage Code	Manufacturer
PS6C6D-L01BK	12324	DUPREE INC. DBA STAKE FASTENER

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

NSNs for Compare ( up to 4 ): Add 5305-01-506-9566

Compare

5305-01-506-9599, 5305-01-506-9906, 5305-01-506-9962, 5305-01-506-9973, 5305-01-506-9976

Characteristic	Specifications
THREAD SERIES DESIGNATOR	UNC
NOMINAL THREAD DIAMETER	0.1380 INCHES
THREAD QUANTITY PER INCH	32
THREAD CLASS	3A
THREAD DIRECTION	RIGHT-HAND
THREAD LENGTH	0.3050 INCHES MINIMUM AND 0.3350 INCHES MAXIMUM
FASTENER LENGTH	0.3450 INCHES MINIMUM AND 0.3750 INCHES MAXIMUM
MATERIAL	PLASTIC NYLON PRIMARY WASHER STEEL FASTENER
MATERIAL DOCUMENT AND CLASSIFICATION	ASTM D4066 90 ASSN STD SINGLE MATERIAL RESPONSE PRIMARY WASHER
SURFACE TREATMENT	CADMIUM FASTENER
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION	QQ-P-416, TY2, CL2 FED SPEC SINGLE TREATMENT RESPONSE FASTENER
COLOR	BLACK OVERALL
HEAD STYLE	C44 FILLISTER
INTERNAL DRIVE STYLE	D2 CROSS RECESS TYPE 11
WASHER QUANTITY	1
PRIMARY WASHER STYLE	G17 FINISHING
SPECIAL FEATURES	COLOR IS LUSTERLESS 30000 SERIES.
III END ITEM IDENTIFICATION	COMM UPGD PH
III PART NAME ASSIGNED BY CONTROLLING AGENCY	SCREW

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

Category	Code	Description
NMF Description	093486	BOLTS,NUTS OR SCREWS, NOI (SUB 3)
Less than car load rating
Less than truck load rating	W	Rating Variable
Water commodity Code	713	unknown
Originating Activity Code	KH	Defense Industrial Supply Center Philadelphia, PA 19111
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	B	Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price Validation	N	The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM. The price has not been analyzed or reviewed for accuracy. ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	J	NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
