NSN 5305-01-409-0197 MS1806731, MS18067-31, NAS1149CN432B
Product Details | SETSCREW
5305-01-409-0197 An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads.
Part Alternates: MS1806731, MS18067-31, NAS1149CN432B , 5305-01-409-0197, 01-409-0197, 5305014090197, 014090197
Hardware and Abrasives | Screws
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 03 MAR 1995 | 01-409-0197 | 06672 ( SETSCREW ) |
Drawings & Photos | NSN 5305-01-409-0197
Demand History | NSN 5305-01-409-0197
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| NAS1149CN432B | 2023-06-165 | 1000 | United States |
| NAS1149CN432B | 2022-04-111 | 1000 | United States |
| NAS1149CN432B | 2021-09-257 | 1000 | United States |
| NAS1149CN432B | 2021-09-246 | 1000 | United States |
| NAS1149CN432B | 2019-12-351 | 1000 | United States |
| NAS1149CN432B | 2018-12-345 | 1000 | United States |
| NAS1149CN432B | 2018-12-345 | 2000 | United States |
| NAS1149CN432B | 2015-08-216 | 2000 | United States |
| NAS1149CN432B | 2014-11-321 | 2000 | United States |
| NAS1149CN432B | 2014-09-265 | 1000 | United States |
| NAS1149CN432B | 2014-07-190 | 1000 | United States |
| NAS1149CN432B | 2013-12-339 | 2000 | United States |
| NAS1149CN432B | 2009-05-124 | 100 | United States |
| NAS1149CN432B | 2008-10-296 | 100000 | US |
| NAS1149CN432B | 2008-05-137 | 350 | US |
| NAS1149CN432B | 2008-05-137 | 350 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5305-01-409-0197
Related Products | NSN 5305-01-409-0197
Technical Data | NSN 5305-01-409-0197
| Characteristic | Specifications |
|---|---|
| THREAD SERIES DESIGNATOR | UNF |
| NOMINAL THREAD DIAMETER | 0.190 INCHES |
| THREAD QUANTITY PER INCH | 32 |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| THREAD LENGTH | 0.306 INCHES MAXIMUM |
| FASTENER LENGTH | 0.437 INCHES NOMINAL |
| MATERIAL | PLASTIC POLYAMIDE LOCKING FEATURE STEEL FASTENER |
| SURFACE TREATMENT | CADMIUM AND CHROMATE FASTENER |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416 TY2 CL3 FED SPEC SINGLE TREATMENT RESPONSE FASTENER |
| HARDNESS RATING | 33.0 ROCKWELL C MINIMUM AND 40.0 ROCKWELL C MAXIMUM FASTENER |
| HEAD STYLE | C101 HEADLESS |
| INTERNAL DRIVE STYLE | D5 HEXAGON |
| WIDTH ACROSS FLATS | 0.0937 INCHES MINIMUM AND 0.0947 INCHES MAXIMUM |
| LOCKING FEATURE | PELLET OR PATCH OR STRIP THREADS |
| POINT STYLE | F16 CONE |
