Product Details | PLAIN CYLINDRICAL PLUG GAGE

5220-01-021-3276 A gage used for the dimensional control of the diameter of a specified hole. It consists of a gaging member or members and handle.

Part Alternates: T1725, T172-5, 5220-01-021-3276, 01-021-3276, 5220010213276, 010213276

Measuring Tools | Inspection Gages and Precision Layout Tools

Supply Group (FSG) NSN Assign. NIIN
52 13 MAY 1976 01-021-3276

Drawings & Photos | NSN 5220-01-021-3276


Demand History | NSN 5220-01-021-3276

Part Number Request Date QTY Origin
T1725 2022-04-118 1 us
5220-01-021-3276 2021-10-290 1 US
5220-01-021-3276 2020-11-306 2 US
T1725 2019-08-231 3 United States
5220-01-021-3276 2018-11-326 3 UK
T1725 2014-01-28 2 United States
5220-01-021-3276 2013-03-78 1 United States

Cross Reference | NSN 5220-01-021-3276

Part Number Cage Code Manufacturer
T172-5 11815 SPS TECHNOLOGIES, LLC DBA CHERRY AEROSPACE DIV
T172-5 F7652 B E AEROSPACE CONSUMABLESMANAGEMENT DEUX SAS
T172-5 R1120 SATAIR A/S

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5220-01-021-3276

Technical Data | NSN 5220-01-021-3276

Characteristic Specifications
DESIGN TYPE DOUBLE END
GAGE TYPE COMBINATION GO NOT GO
GAGING MEMBER OUTSIDE DIAMETER 0.1600 INCHES AND 0.1642 INCHES
GAGING MEMBER OUTSIDE DIAMETER TOLERANCE -0.00020 TO 0.00000 INCHES AND -0.00020 TO 0.00000 INCHES
AIR GROOVE FEATURE NOT INCLUDED
