Product Details | PLAIN MECHANICS PROTRACTOR

5210-01-434-9473 A flat, steel plate of rectangular, square or semicircular shape, graduated in degrees. A pivoted arm is attached to the plate by means of a stationary bolt and thumb nut which locks the arm in any desired position. Used primarily in the metal working trades for laying out and transferring angles, scribing lines, and checking clearances on end mills and the like. Excludes PROTRACTOR, ONE ARM; PROTRACTOR, TWO ARM; PROTRACTOR, THREE ARM.

Part Alternates: 22033, CF19, 5210-01-434-9473, 01-434-9473, 5210014349473, 014349473

Measuring Tools | Measuring Tools, Craftsmen's

Supply Group (FSG) NSN Assign. NIIN
52 12 AUG 1996 01-434-9473

Cross Reference | NSN 5210-01-434-9473

Part Number Cage Code Manufacturer
22033 3JKA4 GENERAL TOOLS MANUFACTURING CO LLC
CF19 3JKA4 GENERAL TOOLS MANUFACTURING CO LLC
CF19 73792 GENERAL HARDWARE MFG CO INC

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5210-01-434-9473

Technical Data | NSN 5210-01-434-9473

Characteristic Specifications
GENERAL CHARACTERISTICS ITEM DESCRIPTION RECTANGULAR HEAD; DOUBLE GRADUATED FROM 0 TO 180 DEG; 6 IN. BLADE LG (GRADUATED IN 32NDS AND 64THS FOR DEPTH MEASURING); SATIN CHROME FINISH; WITH BLADE LOCKNUT
III SUPPLEMENTARY FEATURES INDUSTRIAL QUALITY (IQ) TOOLS PROGRAM ITEM
