NSN 5120-01-510-7486 A1712, A171-2, 68030
Product Details | HAND HYDRAULIC JACK
5120-01-510-7486 A device consisting of a ram, hydraulically actuated by a hand-operated pump(s). The units may be combined on a single base, in a common body or be of the remote control type. The ram is actuated by a hydraulic force in one direction only. Excludes JACK, BUMPER; dolly type jacks; folding tripod type jacks and items with reversing valve mechanisms for performing pulling actions by changing the direction of the hydraulic force applied to the ram.
Part Alternates: A1712, A171-2, 68030, 3ZC62, 5120-01-510-7486, 01-510-7486, 5120015107486, 015107486
Hand Tools | Hand Tools, Nonedged, Nonpowered
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 24 JUL 2003 | 01-510-7486 | 03346 ( JACK, HYDRAULIC, HAND ) |
Drawings & Photos | NSN 5120-01-510-7486
Demand History | NSN 5120-01-510-7486
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5120-01-510-7486 | 2022-09-256 | 2 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5120-01-510-7486
Technical Data | NSN 5120-01-510-7486
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | SELF-CONTAINED |
| LOAD CAPACITY | 12.0 TONS |
| RETRACTED HEIGHT | 9.375 INCHES NOMINAL |
| EXTENDED HEIGHT | 18.500 INCHES NOMINAL |
| SCREW EXTENSION | INCLUDED |
| PUMP TYPE | SINGLE |
| SPECIAL FEATURES | CLEATED SADDLE |
Restrictions/Controls & Freight Information | NSN 5120-01-510-7486
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5120-01-510-7486
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | E | General Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | D | Durable item. An item of Army property coded with an ARC of "D" in the AMDF. Durable items do not require property book accountability after issue from the stock record account, but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded ?D?in the AMDF are considered durable items. |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | M | HANDTOOLS AND SHOP EQUIPMENT |
| Shelf Life Code | 0 | Nondeteriorative |
