NSN 5120-01-101-9720 70700-20394-111, 01-101-9720, 7070020394111
Product Details | DRIFT PUNCH
5120-01-101-9720 A round, square, hexagonal, or octagonal bodied hand tool, having a round tapered section 4 to 6 inches (101.6 mm to 152.4 mm) inclusive in length, which terminates in a flat blunt face. See also PUNCH, DRIVE PIN; PUNCH, ALIGNING; and DRIFTPIN.
Part Alternates: 70700-20394-111, 5120-01-101-9720, 01-101-9720, 5120011019720, 7070020394111, 011019720
Hand Tools | Hand Tools, Nonedged, Nonpowered
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 10 OCT 1980 | 01-101-9720 | 16253 ( PUNCH, DRIFT ) |
Drawings & Photos | NSN 5120-01-101-9720
Demand History | NSN 5120-01-101-9720
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5120-01-101-9720 | 2022-08-231 | 1 | CO |
| 5120-01-101-9720 | 2015-04-111 | 2 | US |
Cross Reference | NSN 5120-01-101-9720
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 70700-20394-111 | 78286 | SIKORSKY AIRCRAFT CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5120-01-101-9720
Related Products | NSN 5120-01-101-9720
Technical Data | NSN 5120-01-101-9720
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 17.000 INCHES NOMINAL |
| SHANK SHAPE | ROUND |
| SHANK DIAMETER | 1.000 INCHES NOMINAL |
| POINT SIZE | 0.250 INCHES |
Restrictions/Controls & Freight Information | NSN 5120-01-101-9720
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI SUB 9 |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | CT | U.S. Army Aviation and Missile Command (AIR) Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5120-01-101-9720
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | E | General Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
