NSN 5120-00-288-9674 GGGW636, GGG-W-636, GGG-W-636 TY8CL2
Product Details | BOX WRENCH
5120-00-288-9674 A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION.
Part Alternates: GGGW636, GGG-W-636, GGG-W-636 TY8CL2, GGGW636TY8CL2, 35524, 35-524, 588, 5120-00-288-9674, 00-288-9674, 5120002889674, 002889674
Hand Tools | Hand Tools, Nonedged, Nonpowered
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 01 JAN 1963 | 00-288-9674 | 03555 ( WRENCH, BOX ) |
Drawings & Photos | NSN 5120-00-288-9674
Demand History | NSN 5120-00-288-9674
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5120-00-288-9674 | 2015-10-288 | 1 | us |
| 5120-00-288-9674 | 2015-07-195 | 2 | us |
| 35524 | 2012-08-236 | 18 | us |
Cross Reference | NSN 5120-00-288-9674
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 35-524 | 03914 | ARMSTRONG BROS TOOL CO |
| 35-524 | 08292 | EASCO HAND TOOLS INC DIV DANAHER TOOL GROUP EASCO HAND |
| 35-524 | 636D0 | APEX TOOL GROUP, LLC |
| 588 | 35377 | MAKINO INC |
| 588 | 65814 | TRW INC HAND TOOLS DIV |
| 588 | 8Z799 | WILLIAMS J H INDUSTRIAL PRODUCTS INC |
| GGG-W-636 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| GGG-W-636 TY8CL2 | 80244 | GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5120-00-288-9674
Related Products | NSN 5120-00-288-9674
Technical Data | NSN 5120-00-288-9674
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| SURFACE TREATMENT | ENAMEL AND PHOSPHATE AND OXIDE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | TT-E-489 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| STYLE DESIGNATOR | 18 STRAIGHT SINGLE HEAD |
| OVERALL LENGTH | 8.750 INCHES MINIMUM AND 11.250 INCHES MAXIMUM |
| OUTSIDE DIAMETER | 1.562 INCHES NOMINAL |
| HEAD THICKNESS | 0.625 INCHES NOMINAL |
| WRENCHING SURFACE SIZE | 0.750 INCHES NOMINAL SINGLE END |
| WRENCHING SURFACE SHAPE | 8 POINT SINGLE END INTERNAL |
| SPECIAL MARKINGS | WRENCH SIZE |
Restrictions/Controls & Freight Information | NSN 5120-00-288-9674
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 186620 | TOOLS, NOI HAND OTHER THAN POWER |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 732 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5120-00-288-9674
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Q | Navy-owned stocks of items accepted by the General Services Administration for support of Navy requirements Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
