NSN 5120-00-194-1498 102839 , 354940-1 AND 91901-1 , 3549401AND919011
Product Details | HAND TERMINAL CRIMPING TOOL
5120-00-194-1498 A hand held tool designed to install various types of terminals on electrical conductors. See also COMPRESSING TOOL, SPLICING SLEEVE.
Part Alternates: 102839 , 354940-1 AND 91901-1 , 3549401AND919011, 52128399, 694781, 69478-1, 5120-00-194-1498, 00-194-1498, 5120001941498, 001941498
Hand Tools | Hand Tools, Nonedged, Nonpowered
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 16 MAR 1970 | 00-194-1498 | 06997 ( CRIMPING TOOL, TERMINAL, HAND ) |
Drawings & Photos | NSN 5120-00-194-1498
Demand History | NSN 5120-00-194-1498
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5120-00-194-1498 | 2020-02-39 | 1 | US |
| 5120-00-194-1498 | 2014-04-118 | 1 | US |
| 5120-00-194-1498 | 2013-10-302 | 1 | US |
| 5120-00-194-1498 | 2012-02-58 | 1 | Canada |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5120-00-194-1498
Technical Data | NSN 5120-00-194-1498
| Characteristic | Specifications |
|---|---|
| REVOLVING DIE FEATURE | NOT PROVIDED |
| OPERATION METHOD | MANUAL COMPRESSION |
| CUTTING JAW | NOT PROVIDED |
| WIRE STRIPPER | NOT PROVIDED |
| WIRE SIZE ACCOMMODATED | 0.0320 AWG NOMINAL |
| MANUFACTURERS CODE | 00779 |
| DESIGN CONTROL REFERENCE | 69478-1 |
Restrictions/Controls & Freight Information | NSN 5120-00-194-1498
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194160 | WASHER OR GASKETS, IRON OR STEEL, |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5120-00-194-1498
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
