NSN 4940-01-114-6831 AA60004III, AA60004-III, 800S
Product Details | SELF-PROPELLED SERVICING PLATFORM
4940-01-114-6831 A self-propolled item designed to provide a safe working platform for overhead or overhead and below the ground level installation, inspection, maintenance, repair, or construction operation. A small floored area (working platform) is mounted on articulated booms which may be rotated in any horizontal plane within the limits of the supporting equipment. The booms are cable and/or hydraulically operated and are controlled by mechanism located within the platform and/or on the vehicle. (Excludes MAINTENANCE PLATFORM and SERVICING PLATFORM, TRACTOR MOUNTED.
Part Alternates: AA60004III, AA60004-III, 800S, 80F, 4940-01-114-6831, 01-114-6831, 4940011146831, 011146831
Maintenance and Repair Shop Equipment | Miscellaneous Maintenance and Repair Shop Specialized Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 49 | 20 JUN 1981 | 01-114-6831 | 22465 ( SERVICING PLATFORM, SELF-PROPELLED ) |
Drawings & Photos | NSN 4940-01-114-6831
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4940-01-114-6831
Technical Data | NSN 4940-01-114-6831
| Characteristic | Specifications |
|---|---|
| OPERATION METHOD | HYDRAULIC |
| OUTRIGGERS | INCLUDED |
| RATED LOAD CAPACITY W/OUTRIGGERS | 500.0 POUNDS |
| PLATFORM LENGTH | 96.000 INCHES NOMINAL |
| PLATFORM WIDTH | 36.000 INCHES NOMINAL |
| PLATFORM GUARD RAIL HEIGHT | 42.000 INCHES NOMINAL |
| PLATFORM INSULATION | NOT INCLUDED |
| PLATFORM MAXIMUM HEIGHT WITH BOOM EXTENDED | 80.000 FEET |
| PLATFORM MAXIMUM HORIZONTAL REACH | 69.250 FEET |
| MAXIMUM BOOM ROTATION IN DEG | 360.0 |
| BELOW SURFACE LEVEL REACH DESIGN FEATURE | NOT INCLUDED |
| OPERATING CONTROL LOCATION | WITHIN PLATFORM |
| POWER SOURCE | INDEPENDENT ENGINE |
| ENGINE MANUFACTURER NAME | JLG INDUSTRIES,INC. |
| ENGINE MODEL NUMBER | 800S |
| OVERALL LENGTH | 36.333 FEET NOMINAL |
| OVERALL WIDTH | 8.000 FEET NOMINAL |
| OVERALL HEIGHT | 11.500 FEET NOMINAL |
| VEHICLE MANUFACTURER NAME | JLG LIFT |
| VEHICLE IDENTIFYING NUMBER | 80F |
| MANUFACTURERS CODE | 58536 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AA60004-III |
Restrictions/Controls & Freight Information | NSN 4940-01-114-6831
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 147650 | OUTFITS MILITARY EQUIP FOR REPAIR |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4940-01-114-6831
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | PD | Regulated items, item manager controlled. |
| Materiel Management Aggregation Code | RN | TG:GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC) |
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
