Product Details | AIRCRAFT ENGINE MAINTENANCE FIXTURE

4920-00-981-7594 A fixture designed to hold/position aircraft engine/engine components to facilitate inspection, maintenance, repair, testing and/or replacement of components.

Part Alternates: 1C2514G3, 4920-00-981-7594, 00-981-7594, 4920009817594, 009817594

Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment

Supply Group (FSG) NSN Assign. NIIN
49 01 JAN 1962 00-981-7594

Cross Reference | NSN 4920-00-981-7594

Part Number Cage Code Manufacturer
1C2514G3 07482 GENERAL ELECTRIC COMPANY DBA GE
1C2514G3 24446 GENERAL ELECTRIC CO

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 4920-00-981-7594

Technical Data | NSN 4920-00-981-7594

Characteristic Specifications
FUNCTIONAL DESCRIPTION USED ON THE COMBUSTION LINER DURING AIRCRAFT MAINTENANCE
III END ITEM IDENTIFICATION J-57 AIRCRAFT ENGINE
MANUFACTURERS CODE 07482
DESIGN CONTROL REFERENCE 1C2514G3

Restrictions/Controls & Freight Information | NSN 4920-00-981-7594

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 093600 BRACKETS/BUSHINGS/JOINTS/MOUNTS ETC
Less than car load rating
Less than truck load rating Q 70.0
Water commodity Code 713 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code Z unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
