Product Details | FLAT VALVE DIAPHRAGM
4820-01-502-5799 An item in the form of one or more thin flexible sheets normally designed to form a tight seal between chambers of a valve, and to transmit motion to a valve disk either directly or through a mechanical linkage. The surface of the item(s) may not be formed or molded to have a beaded or rolled edge, ribs, or any other raised surfaces. The item may contain bolt holes and/or a center hole. Excludes DIAPHRAGM, VALVE, SPECIAL SHAPED and GASKET.20316600062Aircraft Air Conditioning, Heating, and Pressurizing Equipment48100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 10834, 19200NPC8, 4820-01-502-5799, 01-502-5799, 4820015025799, 015025799
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 13 NOV 2002 | 01-502-5799 | 60396 ( DIAPHRAGM, VALVE, FLAT ) |
