NSN 4820-01-393-5323 1741T 1/2IN. 20T24PSI, 1741T12IN20T24PSI, 20221
Product Details | SAFETY RELIEF VALVE
4820-01-393-5323 A valve designed to automatically release excessive pressures. It is actuated by static pressure upstream of the valve and is used as a safety valve or relief valve, and may be set to close at a predetermined pressure. It is not designed for regulation of continuously fluctuating loads. It may be inline or cartridge (manifold) design. Excludes VALVE (1), RELIEF, PRESSURE AND TEMPERATURE.
Part Alternates: 1741T 1/2IN. 20T24PSI, 1741T12IN20T24PSI, 20221, 20221DS41M, 20221F01E0020, 20221F1E0020, 4820-01-393-5323, 01-393-5323, 4820013935323, 013935323
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 21 JUL 1994 | 01-393-5323 | 05488 ( VALVE, SAFETY RELIEF ) |
Drawings & Photos | NSN 4820-01-393-5323
Cross Reference | NSN 4820-01-393-5323
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1741T 1/2IN. 20T24PSI | 01343 | ANDERSON GREENWOOD LP DBA ANDERSON GREENWOOD CROSBY |
| 1741T 1/2IN. 20T24PSI | 15187 | PENTAIR VALVES & CONTROLS US LP DBA NAVY PRODUCT TEAM |
| 20221 | 01343 | ANDERSON GREENWOOD LP DBA ANDERSON GREENWOOD CROSBY |
| 20221DS41M | 01343 | ANDERSON GREENWOOD LP DBA ANDERSON GREENWOOD CROSBY |
| 20221F01E0020 | 15187 | PENTAIR VALVES & CONTROLS US LP DBA NAVY PRODUCT TEAM |
| 20221F1E0020 | 15187 | PENTAIR VALVES & CONTROLS US LP DBA NAVY PRODUCT TEAM |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4820-01-393-5323
Technical Data | NSN 4820-01-393-5323
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY 922 BODY NICKEL ALLOY FLOW CONTROL DEVICE NICKEL ALLOY STEM |
| STYLE DESIGNATOR | C1A ANGLE FLANGED ENDS |
| FIRST CONNECTION FACE TO CENTERLINE DISTANCE | 3.000 INCHES |
| SECOND CONNECTION FACE TO CENTERLINE DISTANCE | 3.000 INCHES |
| VALVE SIZE | 0.500 INCHES |
| FLOW CONTROL DEVICE | DISK |
| VALVE OPERATION METHOD | AUTOMATIC |
| CONNECTION TYPE | FLANGE ALL ENDS |
| FLANGE SHAPE | ROUND WITH HOLES ALL ENDS |
| NOMINAL OUTSIDE DIAMETER | 3.562 INCHES ALL ENDS |
| NOMINAL THICKNESS | 0.375 INCHES ALL ENDS |
| BOLT HOLE QUANTITY | 3 ALL ENDS |
| BOLT HOLE NOMINAL DIAMETER | 0.562 INCHES ALL ENDS |
| BOLT CIRCLE NOMINAL DIAMETER | 2.438 INCHES ALL ENDS |
| FLANGE FACE DESIGN | PLAIN ALL ENDS |
| DISK LOADING METHOD | SPRING |
| ADJUSTABLE PRESSURE RANGE | 20.0 TO 24.0 POUNDS PER SQUARE INCH |
| III END ITEM IDENTIFICATION | TARAWA CLASS LHA |
Restrictions/Controls & Freight Information | NSN 4820-01-393-5323
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 127220 | PRESSURE REG/RED/RELIEF VALVES NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4820-01-393-5323
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
