NSN 4820-00-915-5308 310661, 31066-1, 31537
Product Details | ANGLE VALVE
4820-00-915-5308 A valve with one inlet and one outlet connection with outlet flow at an angle to inlet flow. The flow is controlled by the action of a stem which lifts disks perpendicularly off the center axis of its seat. It may be inline or cartridge (manifold) design. Excludes VALVE (1), Y; VALVE, STOP-CHECK; and COCK, SHUTOFF, SCREW STEM.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 310661, 31066-1, 31537, 4820-00-915-5308, 00-915-5308, 4820009155308, 009155308
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 13 JUL 1966 | 00-915-5308 | 05483 ( VALVE, ANGLE ) |
Drawings & Photos | NSN 4820-00-915-5308
Demand History | NSN 4820-00-915-5308
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 31537 | 2019-01-23 | 2 | United States |
| 4820-00-915-5308 | 2017-04-94 | 1 | DIBBS |
| 4820-00-915-5308 | 2017-01-10 | 29 | DIBBS |
| 4820-00-915-5308 | 2016-11-318 | 29 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4820-00-915-5308
Technical Data | NSN 4820-00-915-5308
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| STYLE DESIGNATOR | A7 ANGLE |
| FLOW CONTROL DEVICE | PLUG |
| MEDIA FOR WHICH DESIGNED | AIR SINGLE RESPONSE |
| MAXIMUM OPERATING PRESSURE | 250.0 POUNDS PER SQUARE INCH SINGLE RESPONSE |
| VALVE OPERATION METHOD | MANUAL |
| CONNECTION TYPE | FLANGE 1ST END THREADED EXTERNAL TUBE 2ND END |
| CONNECTION STYLE | G42 FLARED 2ND END |
| SEAT ANGLE | 37.0 DEGREES 2ND END |
| FLANGE SHAPE | OVAL WITH HOLES 1ST END |
| NOMINAL THICKNESS | 0.308 INCHES 1ST END |
| NOMINAL LENGTH | 2.426 INCHES 1ST END |
| NOMINAL WIDTH | 1.366 INCHES 1ST END |
| BOLT HOLE QUANTITY | 2 1ST END |
| BOLT HOLE NOMINAL DIAMETER | 0.342 INCHES 1ST END |
| BOLT CIRCLE NOMINAL DIAMETER | 1.610 INCHES 1ST END |
| FLANGE FACE DESIGN | PLAIN SWIVEL 1ST END |
| THREAD SERIES DESIGNATOR | UNF 2ND END |
| NOMINAL THREAD SIZE | 0.875 INCHES 2ND END |
| THREAD CLASS | 3A 2ND END |
| THREAD DIRECTION | RIGHT-HAND 2ND END |
| BONNET TYPE | INSIDE SCREW |
| BONNET ATTACHMENT METHOD | INTEGRAL |
| SPECIAL FEATURES | ITEM HAS EXTRA CONNECTION ON SIDE BELOW BONNET THD EXT |
Restrictions/Controls & Freight Information | NSN 4820-00-915-5308
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
