NSN 4820-00-061-5652 MSS SP-80, MSSSP80, B-120 1/2IN
Product Details | GATE VALVE
4820-00-061-5652 A valve having a flat or tapered disk (gate) which moves transversely to the axis of flow by rotating or sliding movements of the stem to open or close the orifice. It may also contain an oval or rectangular shaped slide which may be manually, motor, or pressure operated through the means of an arm or arm assembly. The body flange may be designed to accommodate tube type connectors. It may or may not contain thermal relief features. Includes valve (gate) specifically designed for the control of fluid systems in aircraft or missiles.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: MSS SP-80, MSSSP80, B-120 1/2IN, B12012IN, DS-52228-1/2IN, DS5222812IN, 704, 7715449103, 771-544-9103, B120, 11, 12, 13543F, 13543-F, 2151 1-2, 215112, 2714, 3151 1/2 INCH, 315112INCH, 431, 431 1-2IN, 431-1/2, 43112, 43112IN, 4820-00-061-5652, 00-061-5652, 4820000615652, 000615652
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 01 JAN 1963 | 00-061-5652 | 05482 ( VALVE, GATE ) |
Drawings & Photos | NSN 4820-00-061-5652
Demand History | NSN 4820-00-061-5652
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 11 | 2024-11-324 | 1 | us |
| 4820-00-061-5652 | 2022-11-329 | 32 | DIBBS |
| 4820-00-061-5652 | 2022-11-317 | 32 | DIBBS |
| 4820-00-061-5652 | 2021-06-172 | 25 | DIBBS |
| 12 | 2020-03-84 | 0 | United States |
| 4820-00-061-5652 | 2017-06-155 | 25 | DIBBS |
| 4820-00-061-5652 | 2017-04-100 | 40 | DIBBS |
| 4820-00-061-5652 | 2017-03-87 | 40 | DIBBS |
| 431 | 2011-04-95 | 6 | |
| 431 | 2011-04-95 | 6 | |
| 4820-00-061-5652 | 2009-12-342 | 162 | DIBBS |
Cross Reference | NSN 4820-00-061-5652
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 11 | 63686 | THE WALWORTH COMPANY |
| 11 | 90664 | WALWORTH CO MARINE DIV |
| 12 | 96132 | WALWORTH CO THE |
| 13543-F | 45152 | OSHKOSH CORPORATION |
| 13543-F | 75Q65 | OSHKOSH DEFENSE, LLC |
| 2151 1-2 | 37239 | LUNKENHEIMER CO |
| 2714 | 48422 | WILLIAM POWELL COMPANY THE DBA POWELL VALVE DIV THE STARFLO |
| 3151 1/2 INCH | 37239 | LUNKENHEIMER CO |
| 431 | 14959 | CRANE CO DIV VALVE DIV |
| 431 1-2IN | 14959 | CRANE CO DIV VALVE DIV |
| 431-1/2 | 14959 | CRANE CO DIV VALVE DIV |
| 704 | 86520 | CONBRACO INDUSTRIES INC R-P AND C VALVE DIV |
| 771-544-9103 | 99193 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| B-120 1/2IN | 82666 | STOCKHAM VALVES AND FITTINGS INC |
| B120 | 82666 | STOCKHAM VALVES AND FITTINGS INC |
| DS-52228-1/2IN | 90664 | WALWORTH CO MARINE DIV |
| MSS SP-80 | 59646 | MANUFACTURERS STANDARDIZATION SOCIETY OF THE VALVE AND FITTINGS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4820-00-061-5652
Related Products | NSN 4820-00-061-5652
Technical Data | NSN 4820-00-061-5652
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY 836 BODY COPPER ALLOY SEAT COPPER ALLOY 694 STEM COPPER ALLOY 836 DISK |
| MATERIAL DOCUMENT AND CLASSIFICATION | ASTM B-62 ASSN STD SINGLE MATERIAL RESPONSE BODY ASTM B-371 ALLOY 694 ASSN STD SINGLE MATERIAL RESPONSE STEM ASTM B-62 ASSN STD SINGLE MATERIAL RESPONSE DISK |
| VALVE SIZE | 0.500 INCHES |
| PRESSURE CLASS | 150.0 POUNDS |
| MAXIMUM OPERATING PRESSURE AND MEDIA FOR WHICH DESIGNED | 150.0 POUNDS PER SQUARE INCH STEAM AND 300.0 POUNDS PER SQUARE INCH WATER-OIL-GAS |
| MAXIMUM OPERATING TEMP AND MEDIA FOR WHICH DESIGNED | 406.0 DEG FAHRENHEIT STEAM AND 150.0 DEG FAHRENHEIT WATER-OIL-GAS |
| VALVE OPERATION METHOD | MANUAL |
| INLET RELATIONSHIP WITH OUTLET | IDENTICAL |
| CONNECTION TYPE | THREADED INTERNAL PIPE |
| THREAD SERIES DESIGNATOR | NPT |
| NOMINAL THREAD SIZE | 0.500 INCHES |
| STEM TYPE | RISING |
| BONNET TYPE | INSIDE SCREW |
| BONNET ATTACHMENT METHOD | UNION |
| FURNISHED ITEMS AND QUANTITY | 1 HANDWHEEL |
| FEATURES PROVIDED | BONNET PACKING AND CLEANOUT POCKET |
Restrictions/Controls & Freight Information | NSN 4820-00-061-5652
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
