NSN 4810-01-413-7816 228924, 2289-24, 2289-24 PIECE 9
Product Details | VALVE DISK RETAINER
4810-01-413-7816 An item of various shapes and cross-sections, that may be flanged and that is designed to fit over a valve disk, allowing proper position of disk-to-valve seat within a valve body.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 228924, 2289-24, 2289-24 PIECE 9, 228924PIECE9, 4325677, 508-4325677 PIECE 9, 5084325677PIECE9, 4810-01-413-7816, 01-413-7816, 4810014137816, 014137816
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 23 MAY 1995 | 01-413-7816 | 35917 ( RETAINER, DISK, VALVE ) |
Demand History | NSN 4810-01-413-7816
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4810-01-413-7816 | 2011-07-210 | 64 | DIBBS |
| 4810-01-413-7816 | 2011-05-145 | 15 | DIBBS |
| 4810-01-413-7816 | 2010-11-307 | 11 | DIBBS |
Cross Reference | NSN 4810-01-413-7816
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4810-01-413-7816
Technical Data | NSN 4810-01-413-7816
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-B-24059 AMEND 1 MIL SPEC SINGLE MATERIAL RESPONSE |
| INSIDE DIAMETER | 1.062 INCHES MINIMUM AND 1.281 INCHES MAXIMUM |
| OVERALL LENGTH | 0.875 INCHES NOMINAL |
| NOMINAL THREAD SIZE | 1.750 INCHES |
| VALVE SIZE FOR WHICH DESIGNED | 2.500 INCHES |
| VALVE DESIGN CONTROL ACTIVITY | 80064 |
| III END ITEM IDENTIFICATION | NIMITZ CLASS CVN |
Restrictions/Controls & Freight Information | NSN 4810-01-413-7816
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | N | Ship's parts. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4810-01-413-7816
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
