NSN 4730-01-475-1469 44C4OMXS, 4-4C4OMXS, 864-01-1164
Product Details | PIPE TO TUBE ELBOW
4730-01-475-1469 A fitting that forms an angle of less than 180 degrees (3.142 radians) from the straight flow. One connecting end has standard pipe threads, or is unthreaded and designed to accommodate a pipe. The other end has machine threads (straight threads other than pipe or hose series) designed to accommodate a tube, or is unthreaded and designed to accommodate a tube. It may have side or heel inlet(s). See also ELBOW, PIPE; ELBOW, TUBE; and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE.
Part Alternates: 44C4OMXS, 4-4C4OMXS, 864-01-1164, 4730-01-475-1469, 01-475-1469, 4730014751469, 014751469, 864011164
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 23 MAY 2000 | 01-475-1469 | 03770 ( ELBOW, PIPE TO TUBE ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-01-475-1469
Technical Data | NSN 4730-01-475-1469
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| CONNECTION TYPE | THREADED EXTERNAL HOSE 1ST END THREADED EXTERNAL PIPE 2ND END |
| CONNECTION STYLE | B64 FLARED 1ST END B122 GASKET SEAL 2ND END |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 6.0 MILLIMETERS 1ST END |
| THREAD SERIES DESIGNATOR | UNF 1ST END |
| NOMINAL THREAD SIZE | 0.438 INCHES 1ST END 0.250 INCHES 2ND END |
| THREAD QUANTITY PER INCH | 20 1ST END 19 2ND END |
| THREAD CLASS | 2A 1ST END |
| LEG LENGTH | 22.6 MILLIMETERS NOMINAL 1ST END 31.8 MILLIMETERS NOMINAL 2ND END |
| REDUCED PASSAGE NOMINAL INSIDE DIAMETER | 4.4 MILLIMETERS 1ST END 7.5 MILLIMETERS 2ND END |
| FLOW ANGLE | 90.0 DEGREES |
| FURNISHED ITEMS AND QUANTITY | 1 PREFORMED PACKING AND 1 PREINSERTED RING |
| SPECIAL FEATURES | PIPE THREADS ARE BRITISH STANDARD PIPE - PARALLEL (BSPP); HAS 19.0 MM HEX SHAPED NUT FOR TIGHTENING FITTING |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | C4OMX MALE ELBOW BSPP |
Restrictions/Controls & Freight Information | NSN 4730-01-475-1469
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
