NSN 4730-01-472-6776 MR54047T04, MR54047T-04, AP642T04

Product Details | TUBE COUPLING

4730-01-472-6776 A straight fitting 12 inches (304 mm) long or under having the same or different type of connection of the same size on both ends. It is designed to join a tube or tube fitting to another tube or tube fitting. Excludes fittings with threaded external connections on both ends. Excludes NIPPLE, PIPE.

Part Alternates: MR54047T04, MR54047T-04, AP642T04, 7M523, 7M523T4, 3526004, 35260-04, 4730-01-472-6776, 01-472-6776, 4730014726776, 014726776

Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
47	13 MAR 2000	01-472-6776	06078 ( COUPLING, TUBE )

Drawings & Photos | NSN 4730-01-472-6776

Part Number	Request Date	QTY	Origin
4730-01-472-6776	2024-12-359	2	United States
4730-01-472-6776	2024-10-282	10	Singapore
4730-01-472-6776	2024-09-274	10	Singapore
4730-01-472-6776	2024-09-271	110	United States
4730-01-472-6776	2023-05-125	34	MANUAL
7M523T4	2023-05-125	34	Saudi Arabia
4730-01-472-6776	2023-05-124	40	Saudi Arabia
