NSN 4730-01-466-5469 2540204GV16M, 25402-04G-V16M, 01-466-5469
Product Details | QUICK DISCONNECT ELBOW
4730-01-466-5469 A fluid line fitting shaped to form an angle of less than 180 degrees (3.142 radians) from straight flow. Both ends must have a quick disconnect feature. The fitting may incorporate a self-sealing feature for the purpose of automatically shutting off the flow of fluid when disconnected from a mating quick disconnect feature. For elbow type fluid line fittings with a quick disconnect feature on one end and a pipe, tube or boss connection on the other end, see COUPLING HALF, QUICK DISCONNECT.
Part Alternates: 2540204GV16M, 25402-04G-V16M, 4730-01-466-5469, 01-466-5469, 4730014665469, 014665469
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 23 JUL 1999 | 01-466-5469 | 29761 ( ELBOW, QUICK DISCONNECT ) |
Drawings & Photos | NSN 4730-01-466-5469
Demand History | NSN 4730-01-466-5469
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4730-01-466-5469 | 2019-03-80 | 1 | United States |
| 4730-01-466-5469 | 2019-03-66 | 1 | United States |
| 4730-01-466-5469 | 2018-05-144 | 4 | United States |
| 4730-01-466-5469 | 2018-01-11 | 4 | United States |
| 4730-01-466-5469 | 2015-11-320 | 3 | United States |
| 4730-01-466-5469 | 2015-11-310 | 3 | United States |
| 4730-01-466-5469 | 2015-10-300 | 3 | United States |
| 4730-01-466-5469 | 2015-08-237 | 6 | DIBBS |
| 4730-01-466-5469 | 2015-08-225 | 6 | DIBBS |
| 4730-01-466-5469 | 2015-04-97 | 3 | United States |
| 4730-01-466-5469 | 2014-08-224 | 3 | United States |
| 4730-01-466-5469 | 2014-07-210 | 3 | US |
| 4730-01-466-5469 | 2013-02-52 | 1 | us |
