NSN 4730-01-196-1575 1 1/2X1PTR-S, 112X1PTRS, 20812416S
Product Details | PIPE BUSHING
4730-01-196-1575 A fitting with pipe threads having a female connection inside of a male connection, used in conjunction with another fitting, to connect in the same line, two pipes of different sizes.
Part Alternates: 1 1/2X1PTR-S, 112X1PTRS, 20812416S, 2081-2416S, 2081-24-16S, 24-16 140140C, 2416140140C, 334564P01, 54062416, 5406-24-16, 6024490073, 60244-90073, 7M8212416S, 7M821-24-16S, J514, 4730-01-196-1575, 01-196-1575, 4730011961575, 011961575
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 07 DEC 1984 | 01-196-1575 | 03779 ( BUSHING, PIPE ) |
Drawings & Photos | NSN 4730-01-196-1575
Demand History | NSN 4730-01-196-1575
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 20812416S | 2017-10-290 | 0 | United States |
| 4730-01-196-1575 | 2017-09-262 | 1 | DIBBS-KIT |
| 2081-24-16S | 2017-09-261 | 1 | |
| J514 | 2015-02-48 | 1 | us |
| 4730-01-196-1575 | 2014-01-21 | 156 | DIBBS |
| 4730-01-196-1575 | 2010-06-179 | 21 | DIBBS |
| J514 | 2010-02-47 | 20 | us |
| 4730-01-196-1575 | 2009-06-156 | 21 | DIBBS |
| 4730-01-196-1575 | 2009-04-107 | 21 | DIBBS |
Cross Reference | NSN 4730-01-196-1575
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1 1/2X1PTR-S | 30780 | PARKER-HANNIFIN CORPORATION DBA TUBE FITTINGS DIVISION |
| 1 1/2X1PTR-S | 98441 | PARKER-HANNIFIN CORPORATION DBA STRATOFLEX PRODUCTS DIVISION |
| 2081-24-16S | 01276 | EATON-AEROQUIP INC DIV FLUID CONNECTORS PRODUCTS |
| 2081-2416S | 01276 | EATON-AEROQUIP INC DIV FLUID CONNECTORS PRODUCTS |
| 24-16 140140C | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| 334564P01 | 33654 | HOWDEN FLUID SYSTEMS |
| 334564P01 | 59027 | MEGGITT DEFENSE SYSTEMS, INC. DBA MEGGITT WESTERN DESIGN |
| 334564P01 | 62228 | MEGGITT DEFENSE SYSTEMS, INC. |
| 5406-24-16 | 5E240 | BRENNAN INDUSTRIES |
| 60244-90073 | 97384 | AAI CORPORATION DBA TEXTRON SYSTEMS |
| 7M821-24-16S | 76301 | BOEING COMPANY, THE DBA BOEING |
| J514 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
