NSN 4730-00-772-7680 P58261, 00-772-7680, 007727680
Product Details | HOSE COUPLING
4730-00-772-7680 A straight hose fitting designed to join a hose fitting or to a hose or another hose fitting. For connecting hose to hose fittings it must have two types of hose connections and one connection must have standard hose threads. For connecting two hose fittings it must have two types of hose connections that have standard hose threads of the same size on both ends, only one connection may be externally threaded. Excludes items with self-sealing and/or quick disconnect features.
Part Alternates: P58261, 4730-00-772-7680, 00-772-7680, 4730007727680, 007727680
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 09 APR 1972 | 00-772-7680 | 03340 ( COUPLING, HOSE ) |
Cross Reference | NSN 4730-00-772-7680
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| P58261 | 30299 | FLEXIBLE TECHNOLOGIES INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-772-7680
Technical Data | NSN 4730-00-772-7680
| Characteristic | Specifications |
|---|---|
| MATERIAL | PLASTIC POLYVINYL CHLORIDE OVERALL |
| CONNECTION TYPE | THREADED INTERNAL HOSE 1ST END UNTHREADED EXTERNAL HOSE 2ND END |
| CONNECTION STYLE | B100C PLAIN 1ST END |
| THREAD SERIES DESIGNATOR | NPSH 1ST END |
| NOMINAL THREAD SIZE | 2.000 INCHES 1ST END |
| NOMINAL OVERALL LENGTH | 4.000 INCHES |
| MANUFACTURERS CODE | 30299 |
| DESIGN CONTROL REFERENCE | P58261 |
Restrictions/Controls & Freight Information | NSN 4730-00-772-7680
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051420 | CONDUITS,O/T EARTHEN:PIPE FITTINGS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4730-00-772-7680
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
