NSN 4730-00-606-3876 8167121, 00-606-3876, 006063876
Product Details | PACKING NUT
4730-00-606-3876 An item having internal and/or external machine thread(s) (threads other than pipe or hose series), specifically designed to retain, by means or groove(s), shoulder(s), and the like, packing and/or a packing gland within a stuffing box. See also BUSHING, MACHINE THREAD; INVERTED NUT, TUBE COUPLING; and NUT, TUBE COUPLING. Excludes PACKING NUT, STUFFING TUBE; and use with electrical cable, and LOCKNUT, PIPE.20210150024Guns, 75mm Through 125mm47300051Hose, Pipe, Tube, Lubrication, and Railing Fittings
Part Alternates: 8167121, 4730-00-606-3876, 00-606-3876, 4730006063876, 006063876
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
47 | 01 JAN 1963 | 00-606-3876 | 18028 ( PACKING NUT ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 4730-00-606-3876
Related Products | NSN 4730-00-606-3876
Technical Data | NSN 4730-00-606-3876
Characteristic | Specifications |
---|---|
MATERIAL | BRASS |
SURFACE TREATMENT | OXIDE |
STRENGTH RATING | NOT RATED |
MATERIAL HARDNESS RATING | NOT RATED |
CASEHARDENING INDICATOR | NOT CASEHARDENED |
STYLE DESIGNATOR | C3 ROUND, EXTERNAL THREAD, INVERTED FLARE |
HOLE DIAMETER | 0.125 INCHES NOMINAL |
OVERALL LENGTH | 0.710 INCHES NOMINAL |
SMALLEST INSIDE DIAMETER | 0.635 INCHES NOMINAL |
MAJOR UNTHREADED OUTSIDE DIAMETER | 1.500 INCHES NOMINAL |
HOLE OR SLOT QUANTITY | 4 |
SEAT ANGLE IN DEG | 90.0 |
THREAD SIZE | 1.500-12 |
SCREW THREAD SERIES DESIGNATOR | UNF |
THREAD CLASS | 3A |
THREAD LENGTH | 0.710 INCHES NOMINAL |
THREAD DIRECTION | RIGHT-HAND |
SCREW THREAD LOCATION | EXTERNAL |
Restrictions/Controls & Freight Information | NSN 4730-00-606-3876
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 093486 | BOLTS,NUTS OR SCREWS, NOI (SUB 3) |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 573 | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
