NSN 4730-00-542-5296 M1183/6-12A, M1183612A, CS4730012212CJMN
Product Details | PIPE LATERAL
4730-00-542-5296 A fitting having three connections with the branch connection fixed at various angles other than 90 degrees (1.5705 radians) to the run to permit pipes and/or pipe fittings to be taken off laterally from the main line. It may have side inlet(s).
Part Alternates: M1183/6-12A, M1183612A, CS4730012212CJMN, CS4730-012212CJMN, MILF1183, MIL-F-1183/6, MILF11836, 4730-00-542-5296, 00-542-5296, 4730005425296, 005425296
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1961 | 00-542-5296 | 03802 ( LATERAL, PIPE ) |
Drawings & Photos | NSN 4730-00-542-5296
Demand History | NSN 4730-00-542-5296
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4730-00-542-5296 | 2024-09-267 | 13 | DIBBS |
| 4730-00-542-5296 | 2024-09-256 | 13 | DIBBS |
| 4730-00-542-5296 | 2023-11-320 | 12 | DIBBS |
| 4730-00-542-5296 | 2023-08-222 | 6 | DIBBS |
| 4730-00-542-5296 | 2019-12-353 | 34 | DIBBS |
| MILF1183 | 2019-03-63 | 8 | US |
| 4730-00-542-5296 | 2018-08-235 | 7 | DIBBS |
| MILF1183 | 2017-05-137 | 1 | United States |
| 4730-00-542-5296 | 2013-08-213 | 27 | DIBBS |
| 4730-00-542-5296 | 2013-03-70 | 24 | DIBBS |
| 4730-00-542-5296 | 2013-02-55 | 24 | DIBBS |
| MILF1183 | 2010-11-329 | 100 | FR |
| 4730-00-542-5296 | 2010-03-67 | 17 | DIBBS |
| 4730-00-542-5296 | 2008-11-317 | 3 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4730-00-542-5296
Related Products | NSN 4730-00-542-5296
Technical Data | NSN 4730-00-542-5296
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | ASTM B61 ASSN STD SINGLE MATERIAL RESPONSE OR QQ-C-390 FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| MEDIA FOR WHICH DESIGNED | STEAM 1ST RESPONSE WATER-OIL-GAS 2ND RESPONSE |
| MAXIMUM OPERATING PRESSURE | 200.0 POUNDS PER SQUARE INCH 1ST RESPONSE 400.0 POUNDS PER SQUARE INCH 2ND RESPONSE |
| MAXIMUM OPERATING TEMP | 425.0 DEG FAHRENHEIT 1ST RESPONSE 150.0 DEG FAHRENHEIT 2ND RESPONSE |
| STYLE DESIGNATOR | A90 BRANCHED |
| CONNECTION TYPE | UNTHREADED INTERNAL PIPE ALL ENDS |
| CONNECTION STYLE | B31B STREAMLINED W/ONE BRAZING RING ALL ENDS |
| NOMINAL PIPE SIZE ACCOMMODATED | 4.000 INCHES ALL ENDS |
| LEG LENGTH | 2.010 INCHES NOMINAL 1ST END 6.970 INCHES NOMINAL 2ND END 6.970 INCHES NOMINAL 3RD END |
| SWEEP TYPE | SHORT |
| FURNISHED ITEMS AND QUANTITY | 3 BRAZING RING |
| SPECIFICATION/STANDARD DATA | 81349-MIL-F-1183H GOVERNMENT SPECIFICATION |
| NONDEFINITIVE SPEC/STD DATA | 12 SIZE AND A TYPE |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-F-1183/6 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M1183/6-12A |
Restrictions/Controls & Freight Information | NSN 4730-00-542-5296
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052185 | PIPE,TUBING,OR PIPE OR TUBING FIT |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4730-00-542-5296
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
