NSN 4730-00-283-6397 MR54040T04, MR54040T-04, JCM11495003
Product Details | TUBE COUPLING
4730-00-283-6397 A straight fitting 12 inches (304 mm) long or under having the same or different type of connection of the same size on both ends. It is designed to join a tube or tube fitting to another tube or tube fitting. Excludes fittings with threaded external connections on both ends. Excludes NIPPLE, PIPE.
Part Alternates: MR54040T04, MR54040T-04, JCM11495003, JCM-11495-003, 10108342 , 4730-00-283-6397, 00-283-6397, 4730002836397, 002836397
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 28 AUG 1973 | 00-283-6397 | 06078 ( COUPLING, TUBE ) |
Drawings & Photos | NSN 4730-00-283-6397
Demand History | NSN 4730-00-283-6397
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MR54040T-04 | 2024-03-77 | 524 | DIBBS |
| MR54040T-04 | 2023-12-360 | 329 | DIBBS |
| MR54040T-04 | 2023-12-351 | 329 | DIBBS |
| MR54040T-04 | 2023-08-232 | 114 | DIBBS |
| MR54040T-04 | 2023-05-141 | 148 | DIBBS |
| MR54040T-04 | 2023-01-16 | 128 | DIBBS |
| MR54040T-04 | 2022-09-261 | 102 | DIBBS |
| MR54040T-04 | 2022-05-135 | 154 | DIBBS |
| MR54040T-04 | 2021-12-353 | 381 | DIBBS |
| MR54040T-04 | 2021-09-269 | 201 | DIBBS |
| MR54040T-04 | 2021-05-136 | 231 | DIBBS |
| MR54040T-04 | 2021-02-46 | 159 | DIBBS |
| 4730-00-283-6397 | 2020-09-247 | 2 | US |
| 4730-00-283-6397 | 2018-11-333 | 460 | DIBBS |
| 4730-00-283-6397 | 2018-05-126 | 256 | DIBBS |
| 4730-00-283-6397 | 2018-03-63 | 43 | DIBBS |
| 4730-00-283-6397 | 2017-12-362 | 415 | DIBBS |
| 4730-00-283-6397 | 2017-08-243 | 361 | DIBBS |
| 4730-00-283-6397 | 2015-05-133 | 54 | United States |
| 4730-00-283-6397 | 2014-07-187 | 386 | DIBBS |
| 4730-00-283-6397 | 2014-06-153 | 168 | DIBBS |
| 4730-00-283-6397 | 2014-05-141 | 168 | DIBBS |
| 4730-00-283-6397 | 2014-05-135 | 363 | DIBBS |
| 4730-00-283-6397 | 2014-04-120 | 363 | DIBBS |
| 4730-00-283-6397 | 2014-03-70 | 440 | DIBBS |
| 4730-00-283-6397 | 2014-01-05 | 773 | DIBBS |
| 4730-00-283-6397 | 2013-11-331 | 462 | DIBBS |
| 4730-00-283-6397 | 2013-11-316 | 462 | DIBBS |
| 4730-00-283-6397 | 2013-11-309 | 269 | DIBBS |
| 4730-00-283-6397 | 2013-10-294 | 269 | DIBBS |
| 4730-00-283-6397 | 2013-10-290 | 543 | DIBBS |
| 4730-00-283-6397 | 2013-10-275 | 543 | DIBBS |
| 4730-00-283-6397 | 2013-07-206 | 458 | DIBBS |
| 4730-00-283-6397 | 2013-07-190 | 458 | DIBBS |
| MR54040T04 | 2013-05-140 | 10 | United States |
| 4730-00-283-6397 | 2013-02-58 | 901 | DIBBS |
| 4730-00-283-6397 | 2012-10-285 | 180 | DIBBS |
| 4730-00-283-6397 | 2012-09-263 | 187 | DIBBS |
| 4730-00-283-6397 | 2012-06-164 | 292 | DIBBS |
| 4730-00-283-6397 | 2012-05-129 | 723 | DIBBS |
| 4730-00-283-6397 | 2012-01-19 | 197 | DIBBS |
| 4730-00-283-6397 | 2011-12-362 | 198 | DIBBS |
| 4730-00-283-6397 | 2011-12-349 | 198 | DIBBS |
| 4730-00-283-6397 | 2011-11-314 | 434 | DIBBS |
| 4730-00-283-6397 | 2011-08-238 | 261 | DIBBS |
| 4730-00-283-6397 | 2011-08-222 | 376 | DIBBS |
| 4730-00-283-6397 | 2010-04-106 | 18 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4730-00-283-6397
Related Products | NSN 4730-00-283-6397
Technical Data | NSN 4730-00-283-6397
| Characteristic | Specifications |
|---|---|
| MATERIAL | TITANIUM ALLOY OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 4965,6AL-4V ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| STYLE DESIGNATOR | A5 RIGID, SHORT CENTER WRENCHING FACILITY |
| CONNECTION TYPE | THREADED INTERNAL TUBE 1ST END UNTHREADED INTERNAL TUBE 2ND END |
| CONNECTION STYLE | B12 SWIVEL NUT, FLARELESS 1ST END B40 SOCKET 2ND END |
| SEAT ANGLE | 8.5 DEGREES 1ST END |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 0.250 INCHES 1ST END 0.250 INCHES 2ND END |
| THREAD SERIES DESIGNATOR | NGO 1ST END |
| NOMINAL THREAD SIZE | 0.438 INCHES 1ST END |
| THREAD QUANTITY PER INCH | 24 1ST END |
| THREAD CLASS | 3B 1ST END |
| NOMINAL OVERALL LENGTH | 1.013 INCHES |
| SPECIAL FEATURES | NORMAL OPERATING RANGE IS 3000 TO 8000 PSI AND BURST RANGE IS 12000 PSI |
| III END ITEM IDENTIFICATION | F-16 AND F-18 AIRCRAFT |
Restrictions/Controls & Freight Information | NSN 4730-00-283-6397
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052190 | PIPE,TUBING,OR PIPE OR TUBING FITTI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4730-00-283-6397
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
