NSN 4730-00-278-5029 AN925D10, AN937D10, AN937D10L
Product Details | BOSS CROSS
4730-00-278-5029 A fitting having four branches in the same plane whose axes form right angles. The boss connections for items such as tanks, housings, valve fittings, and the like, have internal or external machine threads (straight threads other than pipe or hose series) and are designed to facilitate a gasket, preformed packing, washer, or the like to form a seal at the boss. It may have side inlet(s). Excludes CROSS, TUBE.
Part Alternates: AN925D10, AN937D10, AN937D10L, AS4875, MILF5509, MIL-F-5509, 4730-00-278-5029, 00-278-5029, 4730002785029, 002785029
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1961 | 00-278-5029 | 22702 ( CROSS, BOSS ) |
Demand History | NSN 4730-00-278-5029
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MILF5509 | 2018-07-201 | 6 | United States |
| 4730-00-278-5029 | 2017-08-215 | 5 | DIBBS |
| 4730-00-278-5029 | 2017-01-20 | 12 | DIBBS |
| MILF5509 | 2009-10-301 | 1 | PK |
| MILF5509 | 2009-02-55 | 100 | US |
Cross Reference | NSN 4730-00-278-5029
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| AN925D10 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| AN937D10 | 00624 | EATON CORPORATION DBA AEROSPACE DIV |
| AN937D10 | 06581 | ALLAN AIRCRAFT SUPPLY CO, LLC |
| AN937D10 | 13899 | HYDRO FITTING MANUFACTURING CORPORATION |
| AN937D10 | 14397 | FABER ENTERPRISES, INC. |
| AN937D10 | 14798 | DESIGNED METAL CONNECTIONS, INC. DBA PERMASWAGE |
| AN937D10 | 22995 | CROWN FITTING CO INC |
| AN937D10 | 30974 | AEROFIT, LLC |
| AN937D10 | 71563 | COLLINS ENGINEERING CORP |
| AN937D10 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| AN937D10L | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| AS4875 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| MIL-F-5509 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-278-5029
Technical Data | NSN 4730-00-278-5029
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 2014 OR ALUMINUM ALLOY 2024 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-A-225/4,T6 FED SPEC SINGLE MATERIAL RESPONSE OR QQ-A-225/6,T6 OR T851 FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | ANODIZE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-A-8625,TYPE 2,CLASS 2 MIL SPEC SINGLE TREATMENT RESPONSE OVERALL |
| CONNECTION TYPE | THREADED INTERNAL BOSS ALL ENDS |
| CONNECTION STYLE | B9 GASKET SEAL ALL ENDS |
| THREAD SERIES DESIGNATOR | UNF ALL ENDS |
| NOMINAL THREAD SIZE | 0.875 INCHES ALL ENDS |
| THREAD CLASS | 3B ALL ENDS |
| LEG LENGTH | 1.160 INCHES NOMINAL ALL ENDS |
| SPECIFICATION/STANDARD DATA | 88044-AN937 GOVERNMENT STANDARD AND 81343-AS4875 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
| MANUFACTURERS CODE | 88044 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AN937D10 |
Restrictions/Controls & Freight Information | NSN 4730-00-278-5029
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
