NSN 4730-00-009-3381 AC1002C04, H985604, H9856-04
Product Details | TUBE ELBOW
4730-00-009-3381 A fitting that forms an angle of less than 180 degrees (3.141 radians) from a straight flow. Both connecting ends have machine threads (straight threads other than pipe or hose series) designed to accommodate a tube or is unthreaded and designed to accommodate a tube. It may have side or heel inlet(s). See also ELBOW, PIPE and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE.
Part Alternates: AC1002C04, H985604, H9856-04, ST57D94, ST57D941, ST57D94-1, ST7M1804, ST7M180-4, LD830654, LD83065-4, D985604, D9856-04, D98564, D9856-4, 10111274 , 4730-00-009-3381, 00-009-3381, 4730000093381, 000093381
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 04 AUG 1972 | 00-009-3381 | 03771 ( ELBOW, TUBE ) |
Drawings & Photos | NSN 4730-00-009-3381
Demand History | NSN 4730-00-009-3381
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AC1002C04 | 2020-03-72 | 508 | DIBBS |
| D9856-04 | 2020-03-72 | 508 | DIBBS |
| H9856-04 | 2020-03-72 | 508 | DIBBS |
| ST7M180-4 | 2020-03-72 | 508 | DIBBS |
| AC1002C04 | 2020-02-34 | 281 | DIBBS |
| D9856-04 | 2020-02-34 | 281 | DIBBS |
| H9856-04 | 2020-02-34 | 281 | DIBBS |
| ST7M180-4 | 2020-02-34 | 281 | DIBBS |
| AC1002C04 | 2019-08-213 | 362 | DIBBS |
| D9856-04 | 2019-08-213 | 362 | DIBBS |
| H9856-04 | 2019-08-213 | 362 | DIBBS |
| ST7M180-4 | 2019-08-213 | 362 | DIBBS |
| AC1002C04 | 2018-08-240 | 24 | United States |
| 4730-00-009-3381 | 2017-12-340 | 296 | DIBBS |
| 4730-00-009-3381 | 2016-09-273 | 316 | DIBBS |
| 4730-00-009-3381 | 2016-06-158 | 303 | DIBBS |
| 4730-00-009-3381 | 2016-04-110 | 153 | DIBBS |
| 4730-00-009-3381 | 2015-10-286 | 205 | DIBBS |
| 4730-00-009-3381 | 2015-06-172 | 110 | DIBBS |
| D985604 | 2014-10-275 | 10 | US |
| AC1002C04 | 2014-09-273 | 10 | US |
| 4730-00-009-3381 | 2014-06-170 | 165 | DIBBS |
| 4730-00-009-3381 | 2013-03-83 | 106 | DIBBS |
Cross Reference | NSN 4730-00-009-3381
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| AC1002C04 | 00624 | EATON CORPORATION DBA AEROSPACE DIV |
| D9856-04 | 14798 | DESIGNED METAL CONNECTIONS, INC. DBA PERMASWAGE |
| D9856-4 | 00624 | EATON CORPORATION DBA AEROSPACE DIV |
| D9856-4 | 14798 | DESIGNED METAL CONNECTIONS, INC. DBA PERMASWAGE |
| H9856-04 | 08199 | EATON AEROSPACE |
| LD83065-4 | 00624 | EATON CORPORATION DBA AEROSPACE DIV |
| ST57D94 | 04236 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN SPACE SYSTEMS |
| ST57D94-1 | 04236 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN SPACE SYSTEMS |
| ST7M180-4 | 76301 | BOEING COMPANY, THE DBA BOEING |
