NSN 4720-00-787-8437 MS22052514, MS22052-5-14, MS24548514
Product Details | AIR BREATHING AIR DUCT HOSE ASSEMBLY
4720-00-787-8437 A length of HOSE, AIR DUCT, AIR BREATHING which may have end couplings on one or both end/or incorporates a communication cable. It is designed for use in breathing oxygen system, air line masks, gas masks, and the like. Excludes items which include the branch or fork hoses; assemblies made up of the oxygen breathing hose, communication cable, wiring for face mask heater, and vent and pressure ducts for the anti-Gsuit and HOSE ASSEMBLY, NONMETALLIC.20342400027Safety and Rescue Equipment47200024Hose and Flexible Tubing65150057Medical and Surgical Instruments, Equipment, and Supplies
Part Alternates: MS22052514, MS22052-5-14, MS24548514, MS24548-5-14, MS4548514, MS4548-5-14, M26626514, M26626-5-14, AE1010010F14, AE1010010F-14, MILH26626, MIL-H-26626, MILPRF26626, MIL-PRF-26626, R3800CCX50140, R3800CCX5-0140, TF169514, TF169-5-14, 1243925CR14, 124392-5CR-14, 1300000514, 13000005-14, 8148650, 4720-00-787-8437, 00-787-8437, 4720007878437, 007878437
Pipe, Tubing, Hose, and Fittings | Hose and Flexible Tubing
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1962 | 00-787-8437 | 30600 ( HOSE ASSEMBLY, AIR DUCT, AIR BREATHING ) |
Drawings & Photos | NSN 4720-00-787-8437
Demand History | NSN 4720-00-787-8437
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4720-00-787-8437 | 2024-04-106 | 72 | DIBBS |
| 4720-00-787-8437 | 2022-10-283 | 1 | IT |
| 4720-00-787-8437 | 2022-04-97 | 70 | DIBBS |
| MS24548514 | 2020-06-160 | 1 | United States |
| 4720-00-787-8437 | 2017-12-353 | 2 | United States |
| 4720-00-787-8437 | 2016-02-35 | 135 | DIBBS |
| 4720-00-787-8437 | 2014-04-105 | 78 | DIBBS |
| 4720-00-787-8437 | 2013-12-354 | 66 | DIBBS |
| MS24548514 | 2013-08-234 | 18 | United States |
| 4720-00-787-8437 | 2013-08-233 | 18 | United States |
| 4720-00-787-8437 | 2013-06-179 | 2 | United States |
| 4720-00-787-8437 | 2013-05-148 | 60 | DIBBS |
| 4720-00-787-8437 | 2012-10-292 | 141 | DIBBS |
| MS24548514 | 2011-02-55 | 10 | United States |
| 8148650 | 2006-04-117 | 10 | US |
Cross Reference | NSN 4720-00-787-8437
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 124392-5CR-14 | 98441 | PARKER-HANNIFIN CORPORATION DBA STRATOFLEX PRODUCTS DIVISION |
| 13000005-14 | 78570 | SMITHS TUBULAR SYSTEMS-LACONIA, INC. |
| 8148650 | 98748 | AIR FORCE UNITED STATES DEPARTMENT OF THE |
| AE1010010F-14 | 00624 | EATON CORPORATION DBA AEROSPACE DIV |
| M26626-5-14 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-H-26626 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MIL-PRF-26626 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MS22052-5-14 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS24548-5-14 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| MS4548-5-14 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| R3800CCX5-0140 | 50599 | PARKER-HANNIFIN CORPORATION DBA STRATOFLEX PRODUCT DIVISION |
| TF169-5-14 | 70510 | HYSPAN PRECISION PRODUCTS, INC. DBA HYSPAN |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4720-00-787-8437
Related Products | NSN 4720-00-787-8437
Technical Data | NSN 4720-00-787-8437
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL CORROSION RESISTING 1ST END COUPLING |
| MATERIAL DOCUMENT AND CLASSIFICATION | QQ-S-763 TYPE 304 FED SPEC SINGLE MATERIAL RESPONSE 1ST END COUPLING |
| SURFACE TREATMENT | PASSIVATE 1ST END COUPLING |
| CROSS-SECTIONAL SHAPE STYLE | B3 ROUND |
| WALL THICKNESS | 0.062 INCHES MINIMUM AND 0.071 INCHES MAXIMUM |
| MEASURING METHOD AND LENGTH | 14.000 INCHES NOMINAL OVERALL |
| CONNECTION TYPE | COUPLING FIRST END |
| COUPLING STYLE | D9 THREADED INTERNAL FIRST END |
| THREAD SERIES DESIGNATOR | UNJF FIRST END |
| NOMINAL THREAD SIZE | 0.500 INCHES FIRST END |
| THREAD QUANTITY PER INCH | 20 FIRST END |
| MAXIMUM OPERATING PRESSURE | 500.0 POUNDS PER SQUARE INCH |
| SPECIAL FEATURES | OZONE RESISTANCE:NOT OZONE RESISTANT; END SIMILARITY:IDENTICAL; INSIDE DIAMETER:0.235 IN. MIN.0.265 IN. MAX.; HOSE STYLE SLEEVE SECTION,STYLE NO. 5 FROM OLD FIIG A22900; HOSE MATERIAL:TETRAFLUOROETHYLENE PLASTIC, CORROSIONN RESISTANT STEEL (QQ-S-763,TYPE 304) AND BRONZE COATED STEEL WIRE; COMMUNICATION CABLE AND RESTRAINT CORD:NOT INCLUDED |
| (NON-CORE DATA) TEMP RANGE | -297.0 TO 260.0 DEG FAHRENHEIT |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-PRF-26626 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | M26626-5-14 |
Restrictions/Controls & Freight Information | NSN 4720-00-787-8437
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | W | 120 months |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051420 | CONDUITS,O/T EARTHEN:PIPE FITTINGS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 736 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4720-00-787-8437
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | BO | SX:BREATHING OXYGEN SYSTEMS AND COMPONENT |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | W | 120 months |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | W | 120 months |
| Purchasing | QTY UOM |
1 EA : Each |
