NSN 4520-01-534-8065 M123094469, M12-3094-469, 01-534-8065
Product Details | NONIMMERSION TYPE ELECTRICAL HEATING ELEMENT
4520-01-534-8065 An electrical device in the form of a resistor consisting of a resistance wire, an insulating material, and may be sheathed. Includes infrared elements. It is designed to transform electrical current into heat. It may include an automatic control to regulate the amount of heat generated.2042540000041300000441000004520000000
Part Alternates: M123094469, M12-3094-469, 4520-01-534-8065, 01-534-8065, 4520015348065, 015348065
Plumbing, Heating, and Waste Disposal Equipment | Space and Water Heating Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 45 | 02 NOV 2005 | 01-534-8065 | 29427 ( HEATING ELEMENT, ELECTRICAL, NONIMMERSION TYPE ) |
Drawings & Photos | NSN 4520-01-534-8065
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4520-01-534-8065
Technical Data | NSN 4520-01-534-8065
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 80 IRREGULAR |
| ELEMENT RADIATION SPECTRUM | NONINFRARED |
| MATERIAL | COPPER RESISTANCE WIRE |
| VOLTAGE IN VOLTS AND CURRENT TYPE | 115.0 AC SINGLE VOLTAGE |
| FREQUENCY IN HERTZ | 60.0 |
| PHASE | SINGLE SINGLE VOLTAGE |
| MAXIMUM WATTAGE RATING IN WATTS | NOT RATED SINGLE VOLTAGE |
| WATT DENSITY RATING | NOT RATED SINGLE VOLTAGE |
| ELEMENT QUANTITY | 2 |
| HEAT QUANTITY | 2 |
| ELEMENT CONNECTION STYLE | 19 IRREGULAR |
| SPECIAL FEATURES | SPIRAL WRAP |
| III END ITEM IDENTIFICATION | POTABLE WATER SYSTEM |
Restrictions/Controls & Freight Information | NSN 4520-01-534-8065
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
