Product Details | PLUMBING FIXTURE DRAIN TRAP

4510-01-195-4481 A piping device usually formed of nonferrous metal which is connected to a plumbing fixture for waste drainage and for the purpose of preventing sewer gas from backing up beyond a desired point by forming a water seal in the line. This is accomplished by its peculiar shape which is usually in the form of a letter P or S.

Part Alternates: 00008587541060, 50373, 54106, 4510-01-195-4481, 01-195-4481, 4510011954481, 011954481

Plumbing, Heating, and Waste Disposal Equipment | Plumbing Fixtures and Accessories

Supply Group (FSG) NSN Assign. NIIN
45 29 NOV 1984 01-195-4481

Drawings & Photos | NSN 4510-01-195-4481


Demand History | NSN 4510-01-195-4481

Part Number Request Date QTY Origin
54106 2020-09-272 1 United States
54106 2019-10-280 1 United States
54106 2019-10-277 1 United States
54106 2019-09-252 25 United States
54106 2019-09-252 1 United States
54106 2018-09-260 100 United States
54106 2018-09-260 100 United States
4510-01-195-4481 2018-03-79 10 DIBBS
4510-01-195-4481 2013-03-62 15 DIBBS
4510-01-195-4481 2009-09-254 15 DIBBS

Cross Reference | NSN 4510-01-195-4481

Part Number Cage Code Manufacturer
00008587541060 59773 P AND M MFG CO DIV OF PLUMBMASTER INC
50373 2W141 P AND M MFG CO
54106 20913 NCH CORPORATION DBA CHEMSEARCH DIVISION
54106 2W141 P AND M MFG CO
54106 59773 P AND M MFG CO DIV OF PLUMBMASTER INC

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 4510-01-195-4481

Technical Data | NSN 4510-01-195-4481

Characteristic Specifications
SHAPE ANY ACCEPTABLE
SWIVEL NOT INCLUDED
MATERIAL BRASS
SURFACE TREATMENT CHROME PLATED
INLET CONNECTION NOMINAL PIPE SIZE ACCOMMODATED 1.500 INCHES
INLET CONNECTION METHOD SLIP JOINT
OUTLET CONNECTION NOMINAL PIPE SIZE ACCOMMODATED 1.500 INCHES
OUTLET CONNECTION METHOD SLIP JOINT
CLEANOUT PLUG NOT PROVIDED

Restrictions/Controls & Freight Information | NSN 4510-01-195-4481

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 052560 TRAPS GREASE R GAS I/S BODY
Less than car load rating
Less than truck load rating S 60.0
Water commodity Code 736 unknown
Originating Activity Code AX Defense Supply Center Columbus
Columbus, OH 43216-5000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity B Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 4510-01-195-4481

Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund CodeSFStock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
