NSN 4510-01-120-9349 20045001, 20045-001, 8101385789
Product Details | FLOOR DRAIN
4510-01-120-9349 A drain through which liquids are drained from floors, shower stalls, or urinal stalls.
Part Alternates: 20045001, 20045-001, 8101385789, 810-1385789, 8101385789TYFSZ2IN, 810-1385789TYFSZ2IN, 8101385789TYPEFSIZE2IN, 810-1385789TYPEFSIZE2IN, 4510-01-120-9349, 01-120-9349, 4510011209349, 011209349
Plumbing, Heating, and Waste Disposal Equipment | Plumbing Fixtures and Accessories
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 45 | 25 OCT 1981 | 01-120-9349 | 08470 ( DRAIN, FLOOR ) |
Drawings & Photos | NSN 4510-01-120-9349
Demand History | NSN 4510-01-120-9349
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4510-01-120-9349 | 2022-07-196 | 1 | United States |
| 8101385789 | 2019-03-63 | 7 | US |
| 4510-01-120-9349 | 2018-01-09 | 45 | DIBBS |
| 4510-01-120-9349 | 2014-06-169 | 32 | United States |
Cross Reference | NSN 4510-01-120-9349
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 20045-001 | 70876 | BATH IRON WORKS CORPORATION |
| 810-1385789 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 810-1385789TYFSZ2IN | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| 810-1385789TYPEFSIZE2IN | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 810-1385789TYPEFSIZE2IN | 80064 | NAVAL SHIP SYSTEMS COMMAND |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4510-01-120-9349
Related Products | NSN 4510-01-120-9349
Technical Data | NSN 4510-01-120-9349
| Characteristic | Specifications |
|---|---|
| OPEN STRAINER | INCLUDED |
| MATERIAL | ALUMINUM ALLOY |
| UNIT TYPE | FLUSH |
| SHAPE | ROUND |
| OPEN STRAINER DIMENSION | 4.093 IN. DIA |
| DESIGN CONFIGURATION | SLOTTED |
| ATTACHMENT METHOD | BOLTED |
| BODY MATERIAL | ALUMINUM ALLOY |
| DOUBLE DRAINAGE FEATURE | NOT PROVIDED |
| INTEGRAL TRAP TYPE | BELL |
| CLAMPING RING | NOT PROVIDED |
| BACKWATER VALVE | NOT PROVIDED |
| CLEAN-OUT FEATURE | NOT INCLUDED |
| REMOVABLE BUCKET | NOT PROVIDED |
| OUTLET PIPE SIZE ACCOMMODATED | 2.000 INCHES |
| OUTLET LOCATION | BOTTOM |
| OUTLET CONNECTION JOINT TYPE | FLANGED |
| LINING MATERIAL | ANY ACCEPTABLE |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | 810-1385789TYFSZ2IN |
Restrictions/Controls & Freight Information | NSN 4510-01-120-9349
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 013120 | ALUMINUM ARTICLE NOI SUB 6 |
| Less than car load rating | ||
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 736 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4510-01-120-9349
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
Z EA : Each |
