NSN 4430-01-530-7978 SN4119312001, WRC5667E4, WRC566-7E4
Product Details | ELECTRIC THERMAL DRYING OVEN
4430-01-530-7978 An oven capable of maintaining and confining heat intensities within close limits. It is designed to be used for aging, baking, curing, drying, heating and/or testing various mechanical equipment or substances.
Part Alternates: SN4119312001, WRC5667E4, WRC566-7E4, 4430-01-530-7978, 01-530-7978, 4430015307978, 015307978
Furnace, Steam Plant, and Drying Equipment; and Nuclear Reactors | Industrial Furnaces, Kilns, Lehrs, and Ovens
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 44 | 13 JUN 2005 | 01-530-7978 | 12824 ( OVEN, THERMAL DRYING, ELECTRIC ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4430-01-530-7978
Related Products | NSN 4430-01-530-7978
Technical Data | NSN 4430-01-530-7978
| Characteristic | Specifications |
|---|---|
| CIRCULATION METHOD | FORCED |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 460.0 |
| FREQUENCY IN HERTZ | 60.0 |
| PHASE | THREE |
| CABINET EXHAUST VENT | PROVIDED |
| SPECIAL FEATURES | SERIAL NUMBER IS 411931 (2001); 1 RECIRCULATING BLOWER WHEEL (FORWARD CURVE, 18IN DIAMETER, CC ROTATION, CARBON STEEL, 1-5/16IN BORE); 1 SHAFT (1-15/16IN DIAMETER X 28IN LONG, 1/2IN X 1/4IN KEY SEAT, 4-1/2IN LONG AT ONE END 3IN LONG ON THE OTHER END); 2 BEARINGS (NP-31, 1-15/16IN DIAMETER BORE PILLOW BLOCKS); 1 HEAT SLINGER (1-15/16IN DIAMETER BORE); 1 MOTOR SHEAVE (2BK40 X 1-1/8IN DIAMETER BORE); 1 SHAFT SHEAVE (2B68Q W/ Q1 BUSHING, 1-15/16IN DIAMETER BORE); 2 BELTS (5L400 "V" BELTS); 4 HINGES (FORGED STEEL STRAPS 21IN LONG); 2 LATCHES (EXPLOSION VENTING P3); 2 HANDLE (31-8); 1 EXHAUSTER BLOWER WHEEL (FORWARD CURVE WHEEL, 12IN DIAMETER, 2-1/2IN DEEP, CARBON STEEL, CW ROTATION, 1-1/2IN LONG HUB OUT, 5/8IN BORE); 1 HEAT SLINGER (5/8IN BORE); 1/2IN ON 48 FRAME MOTORS; PAINT/INTERIOR IS ALUMINIZED STEEL; PAINT/EXTERIOR IS TRILITE GREEN MACHINERY ENAMEL; GASKET IS FIBERGLASS TADPOLE |
| III TYPE/MODEL DESIGNATION | WRC566-750 |
| III END ITEM IDENTIFICATION | OVEN, DRYING, WALK-IN |
Restrictions/Controls & Freight Information | NSN 4430-01-530-7978
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 026740 | OVENS BAKING ELECTRIC STATIONARY |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 659 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4430-01-530-7978
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
