Product Details | RECIPROCATING PUMP

4320-01-384-9477 A positive displacement device which utilizes the reciprocating motion of one or more pistons, plungers, or diaphragms within a complete or partial enclosure as a means of transferring a liquid from one place to another. It is designed to be driven manually or by a prime mover which is not an integral part of the pump.

Part Alternates: 12927638, 4320-01-384-9477, 01-384-9477, 4320013849477, 013849477

Pumps and Compressors | Power and Hand Pumps

Supply Group (FSG) NSN Assign. NIIN
43 28 DEC 1993 01-384-9477

Drawings & Photos | NSN 4320-01-384-9477


Demand History | NSN 4320-01-384-9477

Part Number Request Date QTY Origin
4320-01-384-9477 2024-11-316 45 DIBBS
4320-01-384-9477 2024-09-268 38 DIBBS
4320-01-384-9477 2024-08-219 50 DIBBS
4320-01-384-9477 2024-07-207 6 DIBBS
4320-01-384-9477 2024-06-165 21 DIBBS
4320-01-384-9477 2024-02-56 28 DIBBS
4320-01-384-9477 2024-02-52 1 US
4320-01-384-9477 2024-02-47 1 us
4320-01-384-9477 2024-01-23 1 Australia
4320-01-384-9477 2023-11-324 34 DIBBS
4320-01-384-9477 2023-08-215 15 DIBBS
4320-01-384-9477 2023-04-117 11 DIBBS
4320-01-384-9477 2023-03-87 14 DIBBS
4320-01-384-9477 2022-09-250 20 DIBBS
4320-01-384-9477 2021-03-77 9 DIBBS
4320-01-384-9477 2021-01-21 13 DIBBS
4320-01-384-9477 2019-10-275 44 DIBBS
4320-01-384-9477 2018-04-102 1 United States
4320-01-384-9477 2016-06-158 30 DIBBS
4320-01-384-9477 2016-04-120 32 DIBBS
4320-01-384-9477 2016-04-108 32 DIBBS
4320-01-384-9477 2012-05-131 1 US

Cross Reference | NSN 4320-01-384-9477

Part Number Cage Code Manufacturer
12927638 19200 US ARMY ARDEC RDECOM

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 4320-01-384-9477

Technical Data | NSN 4320-01-384-9477

Characteristic Specifications
PUMPING ELEMENT OPERATING POSITION HORIZONTAL
PUMP RECIPROCATING DESIGN SINGLE ACTING
CYLINDER QUANTITY 1
PUMPING ELEMENT TYPE PISTON
RECIPROCATING STROKE TYPE VARIABLE
OPERATION METHOD MANUAL
DISCHARGE CONNECTION QUANTITY 1
DISCHARGE CONNECTION TYPE QUICK DISCONNECT
III END ITEM IDENTIFICATION M109A6
MANUFACTURERS CODE 19200
DESIGN CONTROL REFERENCE 12927638

Restrictions/Controls & Freight Information | NSN 4320-01-384-9477

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:BMunitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.)
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 127900 MACHINERY:PUMPS HAND/WINDMILL
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 594 unknown
Originating Activity Code BF U.S. Army Armament and Chemical Acquisition and
Logistics Activity
Rock Island, IL 61299-6000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 4320-01-384-9477

Category Code Description
Materiel Category and Inventory ManagerJ Ground Forces Support Materiel (DLA/GSA Items)
Appropriation and Budget Activity2 Stock Fund Secondary Items
Management Inventory Segment1 REPARABLE ITEMS (Exclusive of Insurance and Provisioning Items.) This code will be used to identify serviceable or unserviceable items of a durable nature which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
Specific Group/Generic CodeK Combat Vehicles
Weapons Systems/End Item or Homogeneous GroupKFHowitzer, Full Tracked, Self- propelled 155mm M109
Accounting Requirements CodeX Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDADepartment of the Army
Service OrganizationAU.S. Army
ReparabilityOIf condemned or economically unserviceable, dispose at organizational level.
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
